Available Form Factors
Vehicle Bus Connection: DB15 female
Pin 1
ISO9141 K/
Pins 4, 5: J1850-, J1850+
Pin 6, 7 Ground
Pin 9 Vehicle unswitched Vbat
Pin 10 ISO9141 L
Pin 11 Vehicle Vbat to external scan tool
Pin 12 CAN Low
Pin 13 CAN High
RS-232 Connection:
DB9 female, DCE
Pins 1,4,6 Connected together
Pin 2 RD
Pin 3 TD
Pin 5 Ground
Pin 7 RTS
Pin 8 CTS (Vehicle Ignition Status)
Pin 9 Vehicle Speed Sensor Output Signal, VBAT Power in, VBAT Power out (3 separate build options)
Dimensions: 4.1 x 1.7 x 0.8 in (104.1 x 43.2 x 20.3 mm)
Operating Voltage Range: 8 to 30 VDC
Calculated MTBF: 111,440 Hours
