ultra compact Ethernet serial servers

VESR900 Series - Copper Models

Take control of your serial devices with Vlinx™ VESR9xx Industrial Ethernet
Serial Servers. If it has a Serial Port, it can be monitored and controlled
from anywhere on your Ethernet LAN or WAN. Keep it at maximum
productivity without leaving your office. Even troubleshoot it from outside
your LAN via the Internet. The easy to use Vlinx™ Manager software puts
access to your whole shop on your desk. Configure devices, upgrade
firmware and monitor activity. Configuration changes can also be made
using a web browser.

VESR92x series servers also feature an additional copper RJ45 port that
allows you to connect another Ethernet device or PC work-station. This
Pass-through port functions much like an unmanaged switch.

Heartbeat connectivity keeps the serial server online. If connectivity is lost
it attempts to reconnect every five seconds until connection is regained. A
manual reboot is not needed when communications
are restored.

• Ethernet enable serial devices
• Direct IP, virtual COM port, or paired mode
• Ethernet pass-through port available
• Serial RS-232/RS-422/485 ports
• UL Class 1 Division 2
• NEMA TS2 (VESR901)

accEssorIEs

MDR-40-24 - DIN rail mount power supply 24VDC, 1.7 A output power
ERS35 - 1 M 35mm DIN rail, steel
DRPM25 - 35mm DIN Rail to Panel Mount Bracket
TBKT2 - Replacement Terminal Block, One 5 Position 5.08 mm
TBKT1 - Replacement Terminal Block, One 2 Position 5.08 mm

Product FEaturEs

ordErIng InFormatIon

Model nuMber serial

Ports

serial

ConneCtors

ethernet

Media

ethernet

ConneCtors

VESR901

1

DB9 & TB

CAT 5

RJ45

VESR902D

2

DB9

CAT 5

RJ45

VESR902T

2

TB

CAT 5

RJ45

VESR921

1

DB9 & TB

CAT 5

Two RJ45

VESR922T

2

TB

CAT 5

Two RJ45

* For fiber options please see page 154.

NEMA TS2
