AMU1084, NEMA Type 4X, Fiberglass Reinforced Enclosure
• Compression molded fiberglass reinforced polyester construction with flush, solid/opaque cover
• Allied Moulded Ultraguard TM fiberglass reinforced polyester material formulation
- UV stabilized for outdoor use
• Light gray color (RAL 7035)
• Clear, polycarbonate instrumentation cover
• 304 stainless steel captive cover screws, lockable latches, and hinge pin
• Partially molded hinge and molded latch keeper
• Gasket made of closed cell neoprene cord encased in a continuous tongue and groove channel
• Polycarbonate flanges (mounted) and mounting feet (bagged) with four 304 stainless steel screws
• 10-32 threaded brass inserts are installed for back panel mounting
C O N S T R U C T I O N C O N S T R U C T I O N
A P P L I C A T I O N A P P L I C A T I O N
S T A N D A R D S S T A N D A R D S
• Construction meets NEMA/EEMAC Type 4, 4X, 12 Specifications
• UL
®
508 and UL
®
50 listed, Type 1, 2, 3, 3R, 4, 4X, 12, 13
• CSA certified file LR 89590-1
• Enclosure flammability rating per UL 508
• Joint Industrial Council (JIC) enclosure sizing
• Compliant with RoHS directive - restriction of hazardous substances
10” x 8” x 4” 10” x 8” x 4”
• Designed to insulate and protect controls and components in both indoor and outdoor applications
often found in oil refineries, waste water treatment equipment, and chemical plants
• Especially well suited for high temperature or corrosive environments
• Protects from dirt, dust, oil and water
• For use with industrial control equipment in ordinary locations
• Clear/polycarbonate, instrumentation cover used in applications where critical electronic equipment
must be visible and protected from the elements
Screw Cover Hinged Screw Cover Hinged Snap Latch Hinged Twist Latch
Solid/Opaque AMU1084F AMU1084HF AMU1084LF AMU1084TF
Clear Cover AMU1084CCF AMU1084CCHF AMU1084CCLF AMU1084CCTF
View Window AMU1084WF AMU1084HWF AMU1084LWF AMU1084TWF
Screw Cover Hinged Screw Cover Hinged Snap Latch Hinged Twist Latch
Solid/Opaque AMU1084 AMU1084H AMU1084L AMU1084T
Clear Cover AMU1084CC AMU1084CCH AMU1084CCL AMU1084CCT
View Window AMU1084W AMU1084HW AMU1084LW AMU1084TW
• Flange mount enclosures (flanges installed)
• Foot mount enclosures (four feet bagged and shipped inside enclosure)
Ordering Part Numbers
