PS5R Standard Series
114 www.idec.com
PLCs
Operator Interfaces
Automation Software
Power Supplies
Sensors
Communication & Networking
Power Supplies
Specifi cations
Part
Numbers
PS5R-A05 PS5R-B05* — — — —
PS5R-A12 PS5R-B12 PS5R-C12 — — —
PS5R-A24 PS5R-B24 PS5R-C24 PS5R-D24 PS5R-Q24 PS5R-E24 PS5R-F24 PS5R-G24
Output Capacity 7.5W 15W 30W 50W 75W 100W 120W 240W
Input
Input Voltage (single-
phase, 2-wire) 100 to 240V AC nominal (85 to 264V AC), 50/60Hz (47 to 63Hz)
110 to 340V DC nominal (105 to 370V DC)
100 to 120V AC,
50/60Hz
200 to 240V AC,
50/60Hz
(jumper selectable)
240 to 370V DC
100 to 240V AC, 50/60Hz,
110 to 340V DC
Input Current (typical)
0.17A at
100V AC 0.3A at
100V AC 0.68A at
100V AC 1.15A at
100V AC 1.1A at
100V AC 2.5A at 100V AC
1.5A at 200V AC 1.8A at
100V AC
4A at 100V AC
Internal Fuse Rating 2A 2A 3.15A 3.15A 3.15A 4A 4A 6.3A
Inrush Current 50A maximum (at cold start at 200V AC)
70A maximum
(at cold start at
230V AC) 50A maximum (at
cold start at 200V
AC)
70A maximum (at cold start at
230V AC)
Leakage Current (at
no load)
0.75mA maximum (60Hz, measured in conformance with UL, CSA, VDE)
Typical Effi ciency
69% at 5V
75% at 12V
79% at 24V
75% at 12V
75% at 24V
79% at 24V 83% at 24V 85% at 24V 83% at 24V
Overvoltage Protection Outputs turns off at 105% (typical)
Output
Voltage and Current
Ratings
5V, 1.5A
12V, 0.6A
24V, 0.3A 5V, 2.5A
12V, 1.2A
24V, 0.6A
12V, 2.5A
24V, 1.3A
24V, 2.1A 24V, 3.1A 24V, 4.2A 24V, 5A 24V, 10A
Voltage Adjustments ±10% (V.ADJ screw on top)
Output Holding Time 20ms minimum (at full rated input and output)
Rise Time 200ms maximum (at full rated input and output) 150ms max.
Line Regulation 0.4% maximum
Load Regulation 1.5% maximum
Fluctuation due to
Ambient Temperature
Change
0.05% maximum
Ripple Voltage 2% peak to peak maximum (including noise)
Overload Protection 120% typical (Zener-limiting) 120% typical, auto reset
Operation Indicator LED (green)
Parallel Operation
Allowed PS5R-A PS5R-B PS5R-C PS5R-D PS5R-Q PS5R-E PS5R-F PS5R-G
No Yes No Yes
Dielectric Strength
Between input and output terminals: 3,000V AC, 1 minute
Between input terminals and housing: 2,000V AC, 1 minute
Between output terminal and housing: 500V AC, 1 minute
Insulation Resistance Between input and output terminals/input terminals and housing: 100MΩ minimum (500V DC megger)
Operating Temperature –10˚ to +60˚C (14˚ to 140˚F) (see derating curves)
Storage Temperature –30˚ to +85˚C (-22˚ to 185˚F)
Operating Humidity 20 to 90% relative humidity (no condensation)
Vibration Resistance 45m/s 2 , 10 to 55Hz, 2 hours on each of 3 axes 10 to 50Hz, 0.75mm p-p, 2 hrs on each of 3 axes
Shock Resistance 300m/s 2 (30G), 3 shocks in each of 6 directions
Approvals
Conforms to EMC Directives EN50081-2 & EN50082-2. LVD Directive EN60529 — Certifi ed to EN60950.
UL508 listed. UL, c-UL, TUV approved. CE marked. EN61000-3-2
Weight 150g 170g 360g 390g 800g 600g 1200g 2000g
Termination Spring-up, fi ngersafe terminals with captive M3.5 screws
IP protection IP20 (fi nger safe)
Dimensions H x W x D (mm) 75 x 45 x 70 75 x 45 x95 75 x 90 x 95 75 x 90 x 95 120 x 85 x 140 75 x 145 x 95 120 x 115 x140 120 x 200x 140
Dimensions H x W x D
(inches) 2.95 x 1.77 x
2.76 2.95 x 1.77 x
3.74 2.95 x 3.54 x
3.74 2.95 x 3.54 x
3.74 4.72 x 3.35 x
5.52
2.95 x 5.71 x 3.74
4.72 x 4.53 x
5.52 4.72 x 7.87 x
5.51
1. For dimensions, see page 117.
2. For usage instructions, see page 116.
3. *12.5W for 5VDC model.
