Serial/Single-mode Fiber Converter
FOSTCDRi-ST, FOSTCDRi-SC
SpeCiFiCationS
serial teChnology
Data Rate
9.6 to 115.2 kbps
rs-232
Connector Removable Terminal Block (12 to 28 AWG)
Signals TD, RD, GND
rs-422/485
Connector Removable Terminal Block (12 to 28 AWG)
RS-485, 2-wire
Data A(-), Data B(+), GND
RS-422/485, 4-wire
TDA(-), TDB(+), RDA(-), RDB(+), GND
isolation
Isolation
2KV RMS, 1 minute
Surge Protection
600 W peak power dissipation
Clamping Time
< 1 pico-second
Fiber oPtiC teChnology
Connector
ST
Type / Wavelength
Single-mode / 1310 nm
Output Power
(-) 15 to (-) 8 dBm
Receive Sensitivity
Less than or equal to (-) 32 dBm
Cable
9/125 micro-meter
Data Rate
9.6 to 115.2 kbps
Maximum Distance
15 km (9 mi)
Power
Source
External
Input Voltage
10 to 48 VDC (Class 2)
Power Consumption
1.4 Watts
Connector
Removable terminal block (12 to 28 AWG)
industrial bus
Modbus
ASCII/RTU
MeChaniCal
LED Indicators
FO Receive, FO Transmit, Power
Dimensions
12.8 x 9.7 x 2.8 cm (5.0 x 3.8 x 1.1 in)
Enclosure
35mm DIN Mount, Plastic, IP30
Weight
149.7 g (0.3 lbs)
environMental
Operating Temperature
-40 to +80 °C (-40 to +176 °F)
Storage Temperature
-40 to +85 °C (-40 to +185 °F)
Operating Humidity
0 to 95% non-condensing
MTBF
88423 hours
MTBF Calculation Method Parts Count Reliability Prediction
aPProvals / CertiFiCations - FostCdri-sC
UL 508, File Number: E222870
FCC Part 15, CISPR, EN 55022: 2010 + AC:2011 Class B Emissions
CE
EN 61000-6-1: 2007 Generic Standards for Residential, Commercial and Light-
Industrial Environments
EN 61000-4-2: 2009 Electro-Static Discharge (ESD)
EN 61000-4-3: 2006 +A1 +A2 +IS1 Radiated Field Immunity (RFI)
EN 61000-4-4: 2012 Electrical Fast Transients-Burst Immunity (EFT)
EN 61000-4-6: 2009 Conducted Immunity
Download complete Declaration of Conformity at www.bb.elec.com
FiBer optiC CaBLeS
Multi-Mode duPlex Fiber
length
Model nuMber
ConneCtor tyPe
1M
2M
3M
5M
10M
15M
20M
30M
DFMM-LCLC-XX
LC TO LC
✔
✔
✔
✔
DFMM-SCLC-XX
SC TO LC
✔
✔
✔
✔
✔
DFMM-SCSC-XX
SC TO SC
✔
✔
✔
✔
✔
DFMM-STLC-XX
ST TO LC
✔
✔
✔
✔
✔
DFMM-STSC-XX
ST TO SC
✔
✔
✔
✔
✔
DFMM-STST-XX
ST TO ST
✔
✔
✔
✔
✔
✔
✔
single-Mode duPlex Fiber
length
Model nuMber
ConneCtor tyPe
1M
2M
3M
5M
10M
15M
20M
30M
DFSM-LCLC-XX
LC TO LC
✔
✔
✔
✔
✔
DFSM-SCLC-XX
SC TO LC
✔
✔
✔
✔
✔
DFSM-SCSC-XX
SC TO SC
✔
✔
✔
✔
✔
DFSM-STLC-XX
ST TO LC
✔
✔
✔
✔
✔
DFSM-STSC-XX
ST TO SC
✔
✔
✔
✔
✔
DFSM-STST-XX
ST TO ST
✔
✔
✔
✔
✔
✔
✔
Note: Model Number change the xx to its fiber length number for the actual Model Number.
Example: If you want a 1M Multi-Mode LC to LC Fiber the part number would be DFMM-LCLC-1M.
