Ordering Information
• SFP/XFP Type
• Fiber Link Length • Wavelength
• Bit Rate • Date Code
• Serial Number • Temperature
• Voltage • Bias Current
• TX Power • RX Power
SFP Diagnostics Information
Standard Information Reported: DDMI/Extended Diagnostics Reported
PART
NUMBER
PORT DESCRIPTION FIBER DISTANCE
POWER
BUDGET
W/ DDMI (db)
808-38101 MM850 LC 2 km 14.5
808-38102 MM1300 LC 2 km 11
808-38103 SM1310 LC 20 km 21
808-38104 SM1310/PLUS LC 40 km 31
808-38105 SM1550/LONG LC 80 km 31
Single-Strand Fiber
808-38121 SSFX-SM1310/1550 SC 20 km 20
808-38122 SSFX-SM15501310 SC 20 km 20
808-38123 SSFX-SM1310/1550/PLUS SC 40 km 29
808-38124 SSFX-SM1550/1310/PLUS SC 40 km 29
808-38521 SSFX-SM1310/1550 LC 20 km 20
808-38522 SSFX-SM1550/1310 LC 20 km 20
808-38529 SSFX-SM1310/1550/LONG LC 60 km 29
808-38530 SSFX-SM1550/1310/LONG LC 60 km 29
808-38127 SSFX-SM1490/1550/XLONG SC 80 km 32
808-38128 SSFX-SM1550/1490/XLONG SC 80 km 32
PART
NUMBER
PORT DESCRIPTION FIBER DISTANCE
POWER
BUDGET
W/ DDMI (db)
808-38301 MM850 LC 300 m 7.5
808-38302 SM1310 LC 2 km 8.5
808-38303 SM1310/PLUS LC 15 km 13
808-38304 SM1550/LONG LC 40 km 16
PART NUMBER PORT DESCRIPTION CONNECTOR DISTANCE
808-39001 10 - 1250, TX RJ45 100 m
808-39010 1250, TX RJ45 100 m
PART
NUMBER
PORT DESCRIPTION FIBER DISTANCE
POWER
BUDGET
W/ DDMI (db)
808-38201 MM850 LC 220/550 m 7.5
808-38206 MM1300 LC 2 km 10
808-38200 SM1310 LC 20 km 14
808-38203 SM1310/PLUS LC 30 km 17
808-38204 SM1550/LONG LC 40 km 18
808-38205 SM1550/XLONG LC 70 km 21
808-38208 SM1550/XXLONG LC 120 km 30
Single-Strand Fiber
808-38227 SSBX-SM1310/1490 SC 10 km 12.5
808-38228 SSBX-SM1490/1310 SC 10 km 12.5
808-38221* SSLX-SM1310/1550 SC 20 km 15
808-38222* SSLX-SM1550/1310 SC 20 km 15
808-38223* SSLX-SM1310/1550/PLUS SC 40 km 20
808-38224* SSLX-SM1550/1310PLUS SC 40 km 20
808-38229 SSBX-SM1310/1490/PLUS SC 40 km 21
808-38230 SSBX-SM1490/1310/PLUS SC 40 km 21
808-38225 SSLX-SM1490/1550/LONG SC 70 km 21
808-38226 SSLX-SM1550/1490/LONG SC 70 km 21
All SFPs carry a comprehensive one year warranty.
IE-SFP Modules: 100 to 155 Mbps (OC-3) 2
IE-SFP Modules: 1.25 Gbps Gigabit Ethernet (OC-24) 2
IE-SFP Modules: 2.4 Gbps Gigabit Ethernet (OC-48) 2 SFP Modules: Copper
PART NUMBER DESCRIPTION FIBER DISTANCE
POWER
BUDGET (db)
155 Mbps 1.25 Gbps
155
Mbps
1.25
Gbps
155
Mbps
1.25
Gbps
808-38141 808-38241 CWDM-SM1270 LC 80 km 40 km 29 22
808-38142 808-38242 CWDM-SM1290 LC 80 km 40 km 29 22
808-38143 808-38243 CWDM-SM1310 LC 80 km 40 km 29 22
808-38144 808-38244 CWDM-SM1330 LC 80 km 40 km 29 22
808-38145 808-38245 CWDM-SM1350 LC 80 km 40 km 29 22
808-38146 808-38246 CWDM-SM1370 LC 80 km 40 km 29 22
808-38147 808-38247 CWDM-SM1390 LC 80 km 40 km 29 22
808-38148 808-38248 CWDM-SM1410 LC 80 km 40 km 29 22
808-38149 808-38249 CWDM-SM1430 LC 80 km 70 km 29 22
808-38150 808-38250 CWDM-SM1450 LC 80 km 70 km 29 22
808-38151 808-38251 CWDM-SM1470 LC 80 km 70 km 29 22
808-38152 808-38252 CWDM-SM1490 LC 80 km 70 km 29 22
808-38153 808-38253 CWDM-SM1510 LC 80 km 70 km 29 22
808-38154 808-38254 CWDM-SM1530 LC 80 km 70 km 29 22
808-38155 808-38255 CWDM-SM1550 LC 80 km 70 km 29 22
808-38156 808-38256 CWDM-SM1570 LC 80 km 70 km 29 22
808-38157 808-38257 CWDM-SM1590 LC 80 km 70 km 29 22
808-38158 808-38258 CWDM-SM1610 LC 80 km 70 km 29 22
IE-SFP Modules: CWDM (155 Mbps/1.25 Gbps) with DDMI 3
PART
NUMBER
PORT DESCRIPTION FIBER DISTANCE
POWER
BUDGET ( db )
808-38600 IE-SFP+SR/10G-ED, MM850 LC 33 m 2.8
808-38601 IE-SFP+LR/10G-ED, SM1310 LC 10 km 8.4
IE-SFP+ Modules: 10 Gbps Ethernet (OC-192) with DDMI 1, 2
PART
NUMBER
PORT DESCRIPTION FIBER DISTANCE
POWER
BUDGET ( db )
808-38610 IE-XFP SR/10G-ED, MM850 LC 33 m 2.8
808-38611 IE-XFP LR/10G-ED, SM1310 LC 10 km 8.4
808-38612 IE-XFP ER/10G-ED, SM1550 LC 40 km 15
808-38613 IE-XFP ZR/10G-ED, SM1550/PLUS LC 80 km 23
IE-XFP Modules: 10 Gbps Ethernet (OC-192) with DDMI 1
1 10 Gbps XFP (OC-192) and 10 Gbps SFP+ (OC-192) form factors have varying dimensions and are not
typically interchangeable; this will depend on the device type.
2 10 Gbps SFP+ (OC-192) and Fiber SFPs (OC-3, OC-24 and OC-48) form factors have virtually identical
dimensions and are not typically interchangeable; this will depend on the device type.
3 Models also available without Extended Diagnostics (DDMI).
* Also available with LC connectors
