Documentation Number –PN 9093R1 9POP4-0712qsg
©2010 B&B Electronics Manufacturing Company
5
W
W
i
i
r
r
i
i
n
n
g
g
E
E
x
x
a
a
m
m
p
p
l
l
e
e
P
P
o
o
w
w
e
e
r
r
1.
The two sides of the isolator are
powered from a single +12VDC power
supply and maintain isolation. This
powering configuration allows the
device to be run in any system with
only a single supply, regardless of the
power levels on the RS-232 ports.
2.
In order to maintain the required
isolation, use the recommended
power supply. Using an unregulated
power supply may negate the
isolation.
3.
Recommended Power Supplies:
a. US – 232PS
b. UK – PS1UK-1000
c. EU – PS1EU-1000
L
L
o
o
o
o
p
p
b
b
a
a
c
c
k
k
T
T
e
e
s
s
t
t
Use a DB9 Female to DB9 Male cable to connect a
PC to the DCE port.
(Recommended) Connect a DB9 Female to DB9
Female cable to the DTE port.
On the DTE Port, jumper pin 2 to 3 and pin 7 to 8 on
the female end of the cable. This loops TD to RD and
CTS to RTS.
Using hyper terminal or similar program, connect to
the appropriate COM port (remember to set the baud
rate to 9600).Turn off hyper terminal local echo
Transmit data. The same data should be returned.
