ethernet coaxial extender
for 10/100 networks
EIS-EXTEND-C
regulatory aPProVals
RoHS - Yes
Safety
UL60950-1, EN60950-1, IEC60950-1
EMI
FCC Part 15, Class A
VCCI, Class A
EN61000-6-3
EN55022, EN61000-3-2, EN61000-3-3
EMS
EN61000-6-2
EN61000-4-2 (ESD Standards) Contact: + / - 4KV;
Criteria B Air: + / - 8KV; Criteria B
EN61000-4-3 (Radiated RFI Standards) 10V/m, 80 to
1000MHz; 80% AM Criteria A
EN61000-4-4 (Burst Standards) Signal Ports: + / 2KV;
Criteria B D.C. Power Ports: + / 2KV; Criteria B
EN61000-4-5 (Surge Standards) Signal Ports: + / - 1KV;
Line-to-Line; Criteria B D.C. Power Ports: + / - 0.5KV;
Line-to-earth; Criteria B
EN61000-4-6 (Induced RFI Standards) Signal Ports:
10Vrms @ 0.15~80MHz; 80% AM Criteria A D.C. Power
Ports: 10Vrms @ 0.15~80MHz; 80% AM Criteria A
EN61000-4-8 (Magnetic Field Standards) 30A/m @ 50,
60Hz; Criteria A
Environmental Test
Compliance
IEC60068-2-6 Fc (Vibration Resistance) 5g @
10~150KHz, Amplitude 0.35mm (Operation/Storage/
Transport)
IEC60068-2-27 Ea (Shock) 25g @ 11ms (Half-Sine
Shock Pulse; Operation) 50g @ 11ms (Half-Sine Shock
Pulse; Storage/Transport)
IEC60068-2-32 Ed (Free Fall) 1M (3.281 ft.)
sPecIFIcAtIons
ethernet technology
Standards
IIEEE802.3 10Base-T, IEEE802.3u 100Base-TX,
IEEE802.3x, Ethernet over VDSL
Protocols Transparent to higher layer protocols
Processing Type IEEE802.3x Full-duplex flow control
interFace
Ethernet Port
RJ-45, 10/100Base-TX Full/Half-duplex Auto-
Negotiation, Auto-MDI/MDIX
Speed 10/100Mbps
Distance 328 ft. (100meters)
Cable
10Base-T: UTP CAT. 3, 4, 5 (2-pair wire), 100Base-TX:
UTP CAT. 5 (2-pair wire)
Extender Line Port BNC Coaxial
Speed 1/5/10/20/30/40/50/60/70/75Mbps
Distance 8,530 ft. (2,600meters)
Cable Coaxial Cable (5C2V / RG6AU)
Power
Input Voltage 12 VDC
Power Consumption 5.76W Max. 0.48A@12VDC
enVironMental
Operating Temperature: -10°C to 60°C (14°F to 140°F)
Storage Temperature
-20°C to 70°C (-4°F to 158°F)
Humidity 5% to 95% (non-condensing)
MTBF 57,515 hours
MTBF Calculation Parts count reliability prediction
Mechanical
Enclosure Aluminum case
Dimensions
8.03cm (W) x 10.92cm (D) x 2.38cm (H)
3.16” (W) x 4.30” (D) x 0.94” (H)
Weight 150g (0.33 lb.)
Front Panel leds (ethernet and line connections)
Port leds status description
Ethernet (RJ-45) Pwr Steady Power on (Pwr stands for POWER)
Off Power off
Lnk/Act Steady Valid Ethernet connection established (Lnk
stands for LINK)
Flashing Transmitting or receiving Ethernet data (Act
stands for ACTIVITY)
Off No valid Ethernet connection nor
transmitting/receiving Ethernet data
Fdx Steady Ethernet connection in full duplex mode
(Fdx stands for FULL-DUPLEX)
Flashing Collision occurred
Off Ethernet connection in half-duplex mode
Line (BNC) Rmt Steady The device operates in remote mode
Loc Steady The device operates in local mode
Err Steady Error occurred
Lnk Steady A valid connection established between
local & remote units
toP leds (Bnc line connections)
leds status speed distance
1
Green 1~ 5Mbps up to 2600M
Amber 6~10Mbps up to 2400M
2
Green 11~16Mbps up to 2000M
Amber 17~20Mbps up to 1800M
3
Green 21~29Mbps up to 1600M
Amber 30~43Mbps up to 1400M
4
Green 44~54Mbps up to 1200M
Amber 55~63Mbps up to 1000M
5 Green 64~74Mbps up to 600M
Amber 75~85Mbps up to 200M
