2
FX TX
LED functions are as follows (above illustration is representative):
FX
LNK/ACT Glows green when a link is established on the fiber port; blinks
green when activity is detected on the fiber port.
TX
LNK/ACT Glows amber when a link is established on the copper port; blinks
amber when activity is detected on the copper port.
B&B Electronics Technical Support
Tel: (949) 465-3000 or (800) 624-1070 (in the U.S. and Canada);
+32-16-550880 (Europe)
Fax: (949) 465-3020
E-Mail: [email protected]
Web:
www.imcnetworks.com
Specifications
Ethernet Connections - Fixed Fiber Port
10/100/1000 BaseT, Auto Negotiation, Auto-Cross, Flow Control, 1,536 MTU, Full
Line-Rate Forwarding.
Ethernet Connections - SFP Fiber Port
10/100/1000 BaseT, Auto Negotiation, Auto-Cross, Flow Control, 10,240 MTU, Full
Line-Rate Forwarding.
AC Wall Adapter
100 to 240 ±10% VAC input, 5 VDC output, 2A max.
Operating Temperature
+32°F to +122° F (0°C to +50°C )
Storage Temperature
-31°F to 167° F (-35°C to 75°C)
Humidity
5 to 95% (non-condensing); 0 to 10,000 ft. altitude
Dimensions
0.83”H x 1.80”W x 3.35”D (2.11 x 4.57 x 8.51 cm)
