(Revised 8/5/2009) 6
Functional Overview
The 100-POE4 industrial 4-port Mid-Span POE PSE is designed to provide power over Ethernet for POE
capable devices where running a power line is either not possible or not cost effective. This feature allows
an end user to power a POE camera, wireless access point, or any other POE capable device without the
need for running separate wires for power. This also allows the ability for a centralized battery backup for
all these devices.
Key Features
• Compact, space saving package
• IEEE 802.3af Compliant
• Four 10/100Base-TX RJ-45 Ports (DATA IN)
• Four 10/100Base-TX RJ-45 POE Ports (DATA & POWER OUT)
• Unmanaged operation
• Extended Environmental Specifications
-40°C to 85°C Operating and Storage Temperature
• Operating Humidity: 10% to 90% (Non Condensing)
• Full Wire Speed Communications
• LED POE Status Indication
• Power Fault Status LEDs
• Up to 0.8 Gb/s Maximum Throughput
• Industry Standard 35mm DIN Rail Mounted Enclosure
• Redundant power inputs (46-49 VDC)
• Supports up to 15.4Watts per channel (13 Watts at the Powered Device (PD ))
• Hardened metal DIN Rail Enclosure
