RoHS compliant
1310 nm Single-mode Transceiver (S1.1)
Small Form Pluggable (SFP), 3.3V
155 Mbps SONET OC-3/SDH STM-1/125 Mbps Fast Ethernet
Page 3 of 9
Version 1.0
Date: 11/30/2005 Headquarters :
12 Shyr Jiann Road, Hsinchu Industrial Park, Hukow,
Hsinchu Hsien,, Taiwan 303
TEL: +886-3-5986799
FAX: +886-3-5986655
Website:
www.apacoe.com.tw
Receiver Electro-optical Characteristics
Vcc = 3.1 V to 3.5 V, T
C
= 0
°
C to 70
°
C (-40
°
C to 85
°
C)
PARAMETER SYMBOL MIN TYP. MAX UNITS NOTE
Data Rate B 50 155 200 Mb/s
Optical Input Power -maximum P
IN
0 --- --- dBm Note 1
Optical Input Power –minimum
(Sensitivity)
P
IN
--- ---
−34
dBm Note 1
Operating Center Wavelength
λ
C
1260 --- 1600 nm
Data Output Rise, Fall Time
(10%~90%)
T
r, f
--- 1 2 ns
Loss of Signal-Asserted P
A
--- ---
−34
dBm
Loss of Signal-Deasserted P
D
−45
--- --- dBm
Loss of Signal-Hysteresis P
A
− P
D
1.0 --- --- dB
Differential Output Voltage V
DIFF
0.5 --- 1.2 V
Receiver Loss of Signal Output
Voltage-Low
RX_LOS
L
0 --- 0.5 V
Receiver Loss of Signal Output
Voltage-High
RX_LOS
H
2.4 --- V
CC
V
Note 1: The input data is at 155.52 Mbps, 2
23 −
1 PRBS data pattern. The receiver is guaranteed to provide output data with Bit
Error Rate (BER) better than or equal to 1 Ч 10 –10 .
