RoHS compliant
1310 nm Single-mode Transceiver (S1.1)
Small Form Pluggable (SFP), 3.3V
155 Mbps SONET OC-3/SDH STM-1/125 Mbps Fast Ethernet
Page 2 of 9
Version 1.0
Date: 11/30/2005
Headquarters :
12 Shyr Jiann Road, Hsinchu Industrial Park, Hukow,
Hsinchu Hsien,, Taiwan 303
TEL: +886-3-5986799
FAX: +886-3-5986655
Website:
www.apacoe.com.tw
Recommended Operating Conditions
PARAMETER
SYMBOL
MIN
MAX
UNITS
NOTE
0 70
LS38-A3S-TC-N
Case Operating Temperature
T
C
-40 85
°
C
LS38-A3S-TI-N
Supply Voltage
Vcc
3.1 3.5 V
Supply Current
I
TX
+ I
RX
--- 300 mA
Transmitter Electro-optical Characteristics
Vcc = 3.1 V to 3.5 V, T
C
= 0
°
C to 70
°
C (-40
°
C to 85
°
C)
PARAMETER
SYMBOL
MIN
TYP.
MAX
UNITS
NOTE
Data Rate
B 50
155
200
Mb/s
Output Optical Power
9/125
µ
m fiber
Pout
−15
--- -8 dBm Average
Extinction Ratio
ER
8.2 --- --- dB
Center Wavelength
λ
C
1261 1310 1360 nm
Spectral Width (RMS)
∆
λ
--- --- 4.0 nm
Rise/Fall Time (10
−90%)
T
r,
f
--- 1 2 ns
Max. P
out
TX-DISABLE Asserted
P
OFF
--- ---
−45
dBm
Output Eye
Compliant with Telcordia GR-253-CORE Issue 3 and ITU-T recommendation G-957
Differential Input Voltage
V
DIFF
0.4 --- 2.0 V
