Zlinx Wireless Modbus I/O-0712ds page 4/5
©2009 B&B Electronics. All rights reserved
www.bb-elec.com [email protected] [email protected]
International Office: 707 Dayton Road PO Box 1040 Ottawa, IL 61350 USA 815-433-5100 Fax 433-5104
European Office: Westlink Commercial Park Oranmore Co. Galway Ireland +353 91 792444 Fax +353 91 792445
PR
O
D
U
C
T
INF
ORM
A
TIO
N
B
&
B
ELE
C
T
R
ON
ICS
Software Power (Base Modules)
Supported OS Windows ME/98/2000/XP/Win7 Source An external power supply is required
A software CD is provided with the (not included)
programming kits and contains the Voltage 10-40 VDC, 24 VAC
Zlinx Manager software, Users Manual Class 2, (2.7A Maximum)
and Quick Start Guide. Power Connection
Removable Terminal Block, 3.81
mm spacing
Agency Approvals Wiring Terminals
FCC Part 15 Class A
CE Download DoC at www.bb-elec.com
Download DoC at www.bb-elec.com
Wire Type
Conductors
Wire Range
Tightening Torque
Field Wiring Temp Rating
Power Consumption
SR Models
MR Models
900 MHz LR Models
868 MHz LR Models
Copper Wire Only
One Conductor Per Terminal
28 to 16 AWG
1.7 lb
– in
105°C Minimum (Sized for 60°C
ampacity).
10.0 W
9.5 W
13.1 W
12.0 W
UL/cUL
File Numbers E245458 (Class 1, Div 2) &
E222870 (UL508)
Power (Expansion Modules)
Modules that are Class 1, Div 2 listed: Source
Class 2 Power Derived from
ZZ24D-Nx-SR (2.4GHz, Short range) Base modules
ZZ9D-Nx-LR (900 MHz, Long range) Voltage and current listed on
ZZ-2AI2AO Product label.
ZZ-4AI
ZZ-4AO
ZZ-4AO-2 Power Consumption
ZZ-4DI4DO-DCT ZZ-4AI 1.0 W
ZZ-4DI4DO-DCT1 ZZ-4AO 1.1 W
ZZ-4RTD1 ZZ-2AI2AO 1.2 W
ZZ-8DI-DC ZZ-8DI-DC 0.4 W
ZZ-8DO-R ZZ-8DO-T 15.8 W
ZZ-8DO-T ZZ-8DO-T1 1.1 W
ZZ-8DO-T1 ZZ-4DI4DO-DCT 8.1 W
ZZ-PROG1-USB ZZ-4DI4DO-DCT1 1.0 W
Class 1, Div 2 exceptions: ZZ-8DO-R 3.2 W
ZZ-8DO-R is not UL508 listed ZZ-4RTD1 0.4 W
ZZxxD-Nx-MR, ZZxxD-Nx-xR-AU and
ZZ8D-Nx-xR models are not Class 1, Div
2 listed but are UL508 listed
ZZ-4AO-2 6.0 W
MTBF(Hours) Outputs
ZZ24D-NA-SR 85547 ZZ24D-NB-SR 137106 ZZ-8DO-R Relay Output, 250VAC
ZZ24D-NC-SR 86247 ZZ24D-ND-SR 138362 2 A General Purpose/Point
ZZ24D-NA-MR 88006 ZZ24D-NB-MR 142946 8 A General Purpose Total
ZZ24D-NC-MR 88746 ZZ24D-ND-MR 144909 All Others Low Voltage, Limited Energy
ZZ9D-NA-MR 88006 ZZ9D-NB-MR 144746 Communications Protocol
ZZ9D-NC-MR 88746 ZZ9D-ND-MR 144909 Wiring Terminals
ZZ9D-NA-LR 88195 ZZ9D-NB-LR 143446 Wire Type
ZZ9D-NC-LR 88938 ZZ9D-ND-LR 145422 Conductors Copper Wire Only
ZZ8D-NA-LR 88195 ZZ8D-NB-LR 143446 Wire Size One Conductor Per Terminal
ZZ8D-NC-LR 88938 ZZ8D-ND-LR 145422 Tightening Torque 28 to 16 AWG
ZZ-4AI 136050 ZZ-4AO 113996 Tightening Torque
ZZ-2AI2AO 119183 ZZ-8DI-T 317530 Replacement Parts
ZZ-8DO-T 313100 ZZ-8DO-T1 317530 ZZ-DIN 1 Replacement DIN clip and spring
ZZ-4DI4DO-DCT 197045 ZZ-4DI4DO-DCT1 200795 For all ZZ products, also comes
ZZ-8DO-R 40670 ZZ-4RTD1 243007 with spare screws for enclosure
ZZ-4AO-2 113996 ZZ-TB1 Replacement terminal block kit
for ZZ products. Kit includes
Zlinx Radio Modem Compatibility (1) Two position TB (3.81mm)
Radio Modem Zlinx Base I/O Module (1) Four position TB (3.5mm)
ZP24D-250RM-SR ZZ24D-Nx-SR (1) Eight position TB (3.5mm)
ZP24D-96RM-MR ZZ24D-Nx-SR (1) Cover for local Bus
ZP9D-96RM-MR ZZ9D-Nx-MR ZZ24D-ANT1 2.4 GHZ band antenna
ZP9D-115RM-LR ZZ9D-Nx-LR / ZZ9D-Nx-LR-AU
ZP8D-24RM-LR ZZ8D-Nx-LR
