Specifications
Digital Inputs
Analog Inputs and Outputs
Voltage Range:
0 to 48 VDC
Ranges:
0 to 10 VDC or 0 to 20 mA
Low Voltage (0):
0.8 V maximum
ZZ-4AO-2 is an active current
High Voltage (1):
4.0 V minimum
source. All others are passive
Pull Up Current:
38 micro-amps
Resolution:
12 Bit
Frequency Input:
2 DI inputs per module
Input Accuracy:
0.2% full scale reading typical
Software selectable as
Output Accuracy:
0.27% full scale reading typical
frequency counters,
AI Load Resistance:
100 Mega Ohms when
0 to 5 KHz range.
configured for voltage input
Digital Outputs
250 Ohms when configured
Voltage Range:
10 to 40 VDC (Sourcing)
for current input
0 to 48 VDC (Sinking)
AO Max Output Current:
1 mA when configured for
40 mA per output
voltage output.
AO Max Load
450 Ohms when configured
For current output @ 12V
Relay Outputs
RTD Inputs
Number of Relays:
8
Number of RTD:
4
Type:
C -normally open & normally closed
Wire Configuration:
2, 3, and 4 wire
Output Connection:
3.5mm removable terminal block
Type:
PT100, PT1000 (Optimized for
(2 per output)
temperature coefficient of 385 C),
Common Connection:
3.5mm removable terminal block
Cu10 (Optimized for temperature
Ratings:
250VAC @ 8A, 30VDC @5A (maximum
coefficient of 427 C)
per bank of 4 as grouped on the label)
Input Connection:
3.5mm removable terminal block
(4 per output)
Radio Properties (SR Models)
Temperature Range:
PT100 = (-) 200 to (+) 650 C
Frequency:
2.4 GHz
PT1000 = (-) 200 to (+) 100 C
Output Power :
100 mW
Cu10 = (-) 100 to (+) 260 C
Receiver Sensitivity:
-102 dbm
Resolution:
0.1C cross at (-) 40 to (+) 80 C
Antenna:
The included antenna is a 4.25 inch
Accuracy @ 25 C:
(+/-) 0.5 C typical
omni-directional with RPSMA connector.
Accuracy (-)40 to (+) 80C
(+/-) 2.0 C maximum
(p/n ZZ24D-ANT1)
Radio Properties (2.4 GHz MR Models)
Radio Properties (900 MHz LR Models)
Frequency:
2.4 GHz
Frequency:
900 MHz
Output Power:
50mW
Output Power:
1W
Receiver Sensitivity:
105 dbm @ 9.6K
Receiver Sensitivity:
-100 dbm @ 115.2 K, -110 dbm @
9.6 K
Antenna:
The included antenna is a 4.25 inch
Antenna:
The included antenna is a 6.5 inch
omni-directional with RPSMA connector.
omni-directional with RPSMA
p/n ZZ24D-ANT1
connector p/n ZZ9D-ANT1
Radio Properties (900 MHz MR Models)
Radio Properties (868 MHz LR Models)
Frequency:
900 MHz
Frequency:
868 MHz
Output Power:
100 mW
Output Power:
315 mW
Receiver Sensitivity:
-100 @ 9.6K
Receiver Sensitivity:
-112 dbm
Antenna:
The included antenna is a 6.5 inch
Antenna:
The included antenna is a 6.5 inch
omni-directional with RPSMA connector.
omni-directional with RPSMA
p/n ZZ9D-ANT1
connector p/n ZZ9D-ANT1
LED Indicators
Environmental
Receive Signal Strength:
Tri-color
– Off = No Signal
Operating Temperature
Red = Weak Signal
ZZ-8DO-R
-40 to 55°C (-40 to 131°F)
Yellow = Medium Signal
All Others
-40 to 80°C (-40 to 176°F)
Green = Strong Signal
Maximum Ambient Air Temp
RF Data:
Green
– Blinks with TD or RD
ZZ-8DO-R
55°C (131°F)
Off = No Data
All Others
80°C (176°F)
Local Bus Data:
Green
– Blinks with TD or RD
Storage Temperature
-40 to 85°C (-40 to 185°F)
Off = No Data
Operating Humidity
0 to 95% Non-condensing
Power:
Red
– On = Power applied
Enclosure
Plastic IP30
Off = No Power
Mounting
35mm DIN Rail
Expansion
1 Base Module supports up to 6
Expansion Modules
Dimensions
1.2 x 3.7 x 5.0 in
(2.9 x 9.3 x 12.7 cm)
