BENEFITS
PoE Industrial Network Switch
• Compact Size / Small Footprint
• Ability to Power Devices via LAN
• Eliminates need for Costly Electrical Wiring
• Extended Environmental Specifi cations
• Hardened Metal DIN-Rail Enclosure
• High Performance
• High MTBF >2M Hours
• ESD Protection Diodes on RJ-45 Ports
• Surge Protection Diodes on Power Inputs
Ease of Use
• Plug & Play Operation
• Auto Sensing 10/100BaseTX
• Auto Sensing Full/Half Duplex
• MDIX Auto Cable Sensing
• Unmanaged Operation
• Auto-Detection of PoE Capable Devices
• Redundant Power Status LED's
Increased Performance
• Full Wire Speed Capable
• Full Duplex Capable
• Eliminates Network Collisions
• Increases Network Determinism
• Auto-Disconnect of PoE Port if Fault is Detected
105FX-POE SPECIFICATIONS
Case Dimensions
Height: 3.5"
(9.7cm)
Width: 1.5" (3.8 cm)
Depth 3.6" (9.0cm)
Weight: 0.7 lbs. (0.3 kg)
DIN-Rail: 35mm
Electrical
Input Voltage:
46-49 VDC
Steady Input Current 1.6 A@48V
Under Full Load
Steady Input Current with 65mA@48V
No PoE, Switch Full Load
Inrush: 26Amp/1.3ms@48V
Environmental
Operating Temperature:
-40 o C to 85 o C
Storage Temperature: -40 o C to 85 o C
Operating Humidity: 10% to 95%
(Non Condensing)
Operating Altitude: 0 to 10,000 ft.
Network Media
10BaseT: >Cat3
Cable
100BaseTX: >Cat5 Cable
100BaseFX Multimode 50-62.5/125 μm
100BaseFX Singlemode: 7-10/125 μm
Ordering Information
105FX-XX-POE Four10/100BaseTX Ports (4 PoE)
One 100BaseFX Multimode Port
105FXE-XX-YY-POE Four10/100BaseTX Ports (4 PoE)
One 100BaseFX Singlemode Port
NTPS-48-5 DIN-Rail Power Supply
48V@ 5 Amp
THE INDUSTRIAL NETWORK COMPANY
100 Mb Fiber Transceiver Characteristics
* Multimode Fiber Optic Cable
** Singlemode Fiber Optic Cable
Fiber Length 2km* 15km** 40km** 80km**
TX Power Min -19dBm -15dBm -5dBm -5dBm
RX Sensitivity Max -32dBm -29dBm -34dBm -34dBm
Wavelength 1310nm 1310nm 1310nm 1550nm
Regulatory Approvals
FCC Title 47 Part 15 Class A
ICES-003- Class A
CE: EN61000-6-2,4; EN61000-4-2,3,4,5,6
EN55011
UL Listed (US and Canada) per ANSI/ISA-12.12.01-2000,
Class I, Div 2, Groups A,B,C,D,T4A;
ABS Type Approval for Shipboard Applications
DNV Type Approval Certifi cation
EN50155 for Railway Applications
GOST-R Certifi ed; RoHS Compliant
Designed to comply with:
IEEE 1613 for Electric Utility Substations
and NEMA TS1/TS2 for Traffi c Control Equipment
Connectors
10/100BaseTX+PoE:
Four (4) RJ-45
TX/PoE Copper Ports
100BaseFX: One (1) ST or SC
Duplex Port
Recommended Wiring Clearance
Front:
4" (10.16 cm)
Top: 1" (2.54 cm)
