802.11a 5GHz
DataRate Avg TX ±2dB
1-24Mbps 24 dBm
36Mbps 22 dBm
48Mbps 20 dBm
54Mbps 19 dBm
802.11b/g 2.4GHz
DataRate Avg TX ±2dB
1-24Mbps 24 dBm
36Mbps 22 dBm
48Mbps 20 dBm
54Mbps 19 dBm
802.11n 2.4GHz 5GHz
DataRate Avg TX ±2dB
MCS0 24dBm 24dBm
MCS1 24dBm 24dBm
MCS2 24dBm 24dBm
MCS3 22dBm 22dBm
MCS4 22dBm 22dBm
MCS5 22dBm 22dBm
MCS6 18dBm 18dBm
MCS7 15dBm 15dBm
MCS8 24dBm 24dBm
MCS9 24dBm 24dBm
MCS10 22dBm 22dBm
MCS11 20dBm 20dBm
MCS12 20dBm 20dBm
MCS13 17dBm 17dBm
MCS14 17dBm 17dBm
MCS15 15dBm 15dBm
www.n-tron.com
SPECIFICATIONS
Physical
Height: (w/o antennas): 5.2" (13.2 cm)
Width: 7.4" (18.8 cm)
Depth (includes DIN-Rail mount): 1.5" (3.9 cm)
Weight (max): 1.9 lbs (0.9 kg)
DIN-Rail Mount: 35 mm
Environmental
Operating Temperature: -40 o C to 70 o C
Storage Temperature: -40 o C to 85 o C
Operating Humidity: 5% to 95% (non condensing)
Operating Altitude: 0 to 10,000 ft.
N-TRON Power Supply: NTPS-24-1.3 (sold separately)
Electrical
Redundant Input Voltage: 20-49 VDC (regulated)
Input Current (max): 200 mA max @ 24 VDC
702-W Max Power: 4.8 watts max
Input Ripple: Less than 100 mV
Reliability
MTBF: >1 million hours
Network Media
10BaseT: ≥Cat3 cable
100BaseTX: ≥Cat5 cable
802.11abgn: Air
Connectors
10/100BaseTX: One (1) RJ-45 copper port; PoE-powered device support
802.11abgn: (3) RP-SMA connectors
Recommended Wiring Clearance (Antenna Dependent)
Front: 4" (10.2 cm)
Side: 4" (10.2 cm)
Top: 6" (15.3 cm)
Regulatory Approvals
• Safety: UL 508 and 1604
• Hazardous Location: Class I, Div 2, Groups A, B, C, D, T4A;
ANSI/ISA-12.12.01-2007
• EMI: FCC/CE (CFR 47, Part 15, Subpart B - Class A); ANSI C63.4;
• EMC: R&TTE Directive 99/5/EC ; EN 301 489-3; IEC 61000-4-2 (ESD);
IEC 61000-4-3 (RS)
• GOST-R Certifi ed
• ROHS compliant
702-W
Radio Output Power:
Up to 250mW US
Radio Receiver Sensitivity:
802.11a 5GHz
DataRate Sens. ±3d B
1-24Mbps -96 dBm
36Mbps -95 dBm
48Mbps -94 dBm
54Mbps -91 dBm
802.11b/g 2.4GHz
DataRate Sens. ±3dB
1-24Mbps -97 dBm
36Mbps -90 dBm
48Mbps -86 dBm
54Mbps -84 dBm
802.11n 2.4GHz 5GHz
DataRate Sens. ±3dB
MCS0 -97dBm -96dBm
MCS1 -96dBm -95dBm
MCS2 -93dBm -92dBm
MCS3 -91dBm -90dBm
MCS4 -87dBm -86dBm
MCS5 -84dBm -83dBm
MCS6 -78dBm -77dBm
MCS7 -75dBm -74dBm
MCS8 -96dBm -95dBm
MCS9 -94dBm -93dBm
MCS10 -91dBm -90dBm
MCS11 -88dBm -87dBm
MCS12 -85dBm -84dBm
MCS13 -80dBm -79dBm
MCS14 -79dBm -78dBm
MCS15 -76dBm -75dBm
Designed to comply with:
IEEE 1613 for Electric Utility Substations
NEMA TS1/ TS2 for Traffi c Control
