B&B Electronics 702-W-PM - Datasheet User Manual
Page 2

www.n-tron.com
702-W
Scenario 1 – Basic Bridge
For added security, the 702-W supports WEP, WPA
™
, and WPA2
™
. WPA and WPA2, TKIP (Temporal Key Integrity Protocol) and CCMP (counter mode with Cipher Block
Chaining Message Authentication Code Protocol) are available.
Access Point:
The "access point" mode allows the
702-W to serve as a wireless switch
for the wireless stations attached to it.
Wireless access points are commonly
used to create one wireless local
area network (WLAN) that spans an
area around the access point. Each
access point typically supports up to
253 stations.
Station:
In "station" confi guration, the 702-W is
used to connect a single device (MAC
address) to a wireless access point.
Scenario 2 – Control Network
In station WDS mode, the 702-W can be connected to a remote wired Ethernet switch with multiple devices connected to the switch.
