Accessories
DRAD35 35mm DIN Rail Mounting Kit
Operation

A detailed operating manual is contained on the CD ROM which ships with the product.

Vlinx ESP Manager allows easy access to the serial server to configure the server and ports, upgrade
server firmware and monitor port status and activity. When ESP Manager opens it will search for and
display all ESP90x serial servers on the network. The Monitor Port feature allows you to use any PC on
the LAN/WAN to actively view and troubleshoot the communications status. It shows when there is a
client connection to the server and the client IP address. It displays the number of bytes transmitted and
received as well as the status of the hardware handshaking lines

ESP901/ESP902/ESP904 serial servers can be accessed and configured from any web browser (such
as Internet Explorer) on the LAN/WAN. This allows you to remotely manage the software and your
serial device. It also allows off-site troubleshooting.

ESP901/ESP902/ESP904 serial servers provide automatic resumption of the TCP data connection in
case of a power failure or loss of an Ethernet connection on either the client or server. Once the
Heartbeat connection is established the server sends a signal to the client every five seconds. If the
signal is not received, the serial server will attempt to reconnect the TCP data connection every five
seconds until communication is established again
.
Specifications
Serial Ethernet
Serial Interfaces: RS-232 (DTE), RS-422, RS-485 (2/4-Wire) Connector: RJ-45 F
DIP Switch Selectable Data Rate: 10/100 Mbps Auto-detecting 10BaseT or
Serial Connectors: ESP901: 1 x DB9 Male 1000BaseTx
*ESP902: 2 x DB9 Male Protocols: TCP, IP, ARP, DHCP, Telnet, HTTP, UDP
ESP904: 4 x DB9 Male ICMP
Baud Rate: 110 to 230.4 kbps, 5787 bps
Parity: None, Even, Odd, Mark, Space Configuration
Data Bits: 5, 6, 7, or 8 Console: RS-232 w/ VT100 Emulation
Stop Bits: 1, 1,5, or 2 Telnet: HyperTerminal w/VT100 Emulation
Buffer: 8 Kb per port ESP Manager: Compatible with Windows 2000, XP (32/64 bit)
Note: Refer to the manual for pin-outs and signals.
Server 2003 (32/64 bit), Vista (32/64 bit),
Server 2008 (32/64 bit), Win 7 (32/64 bit)
*ESP902 has (1) RS-232/422/485 port and (1) RS-232 port HTTP: Embedded Web Page
Power (Power Supply Included) Environment
Voltage: 12 VDC Operating Temp: -14 to 176 F (-10 to 80 C)
Current ESP901: 200 mA Storage Temp: -4 to 185 F (-20 to 85 C)
ESP902: 300 mA Humidity: 5 to 90% Non-condensing
ESP904: 500 mA Dimensions:
Connector: 2.5 mm Jack (Positive Tip) ESP901 3.4 x 4.5 x 0.90 in (8.5 x 11.5 x 2.3 cm)
ESP902 3.4 x 4.5 x 0.90 in (8.5 x 11.5 x 2.3 cm)
ESP904 4.5 x 7.3 x 1.1 in (11.4 x 18.5 x 2.9 cm)
Enclosure: IP 30
Approvals: CE, FCC
