1
About the iMcV-10G-Converter XFP/XFP
The iMcV-10G-Converter is a dual wide module that can be installed in an
iMediaChassis series, a MediaChassis /2 or an IE-MediaChassis/2.
The iMcV-10G-Converter is a media converter module with XFP ports which can
provide a conversion between different fiber types or copper to fiber. Fiber types
include Single Mode (SM) and Multi Mode (MM). The supported transmission speeds
are: 10G Ethernet, 10G Sonet/SDH, 10G Fiber channel and 10G OTN. The copper
SFP supports 10G Ethernet only.
For information about the iMcV-10G-Converter refer to the IMC Networks web site
at:
http://www.imcnetworks.com/Support/Downloads.cfm
Configuration Instructions
The iMcV-10G-Converter modules have user-configurable features (e.g., Loss Carry
Forward (LCF), speed (based on protocol selection) and loopback.
Installing an iMcV-Modules
The iMcV-10G-Converter can be installed in IMC Networks’ SNMP manageable
iMediaChassis, MediaChassis/2 AC or DC, or IE-MediaChassis/2 AC or DC.
NOTE
All modules are hot-swappable.
To install an iMcV-10G-Converter:
1. Remove the blank bracket covering the slot where the module is to be installed
by removing the screws on the outside edges of the bracket.
2. Slide the iMcV-10G-Converter into the chassis, via the cardguides, until the
module is seated securely in the connector.
3. Secure the module to the chassis by tightening the captive screw.
4. Save any “blanks” removed during installation for future use if the configuration
requirements change.
