7018TX Specifi cations
Switch Properties
Number of MAC Addresses: 8,000
Aging Time: Programmable
Latency Typical: 2.6
μs
Switching Method: Store-and-Forward
Case Dimensions
Height: 2.3" (5.8 cm)
Width: 8.3" (21.0 cm)
Depth: 4.8" (12.1 cm)
Weight (max): 3.3 lbs (1.5 kg)
DIN-Rail Mount: 35mm
Electrical
Redundant Input Voltage: 10-30 VDC (Regulated)
Input Current (max): 520mA max. @ 24VDC
N-TRON Power Supply: NTPS-24-1.3 (1.3A@24V)
Environmental
Operating Temperature: -40 o C to 70 o C
Storage Temperature: -40 o C to 85 o C
Operating Humidity: 5% to 95%
(Non Condensing)
Operating Altitude: 0 to 10,000 ft.
Shock and Vibration (bulkhead mounted)
Shock: 200g @ 10ms
Vibration/Seismic: 50g, 5-200Hz, Triaxial
Reliability
MTBF: >2 Million Hours
Network Media
10BaseT: >Cat3 Cable
100BaseTX: >Cat5 Cable
1000BaseT: >Cat5e Cable
1000BaseSX Multimode: 50-62.5/125μm
1000BaseLX Singlemode: 7-10/125μm
THE INDUSTRIAL NETWORK COMPANY
7018TX Industrial Ethernet Switch Ordering Information
7018TX Sixteen 10/100BaseTX Ports , Two Optional Gigabit SFP Ports
NTSFP-TX Optional SFP (Mini-GBIC) Transceiver with One 1000BaseT GB Copper Port
NTSFP-SX Optional SFP (Mini-GBIC) Transceiver with One 1000BaseSX Multimode GB Fiber Optic Port
NTSFP-LX-ZZ Optional SFP (Mini-GBIC) Transceiver with One 1000BaseLX Singlemode GB Fiber Optic Port
NTPS-24-1.3 N-TRON Power Supply - (1.3 Amp @ 24VDC)
700-PM Panel Mount kit
URMK Universal Rack Mount Kit
Where: ZZ = 10, 40, or 70 for GB Singlemode
If SFP Transceiver is not specifi ed at the time of purchase, slots will remain blank with covers
SFP Gigabit Fiber Transceiver Characteristics
* SX Fiber Optic Cable
** LX Fiber Optic Cable
Fiber Length 550m for 50/125μm 10km** 40km** 70km**
TX Power Min -9.5dBm/-4dBm -9.5dBm/-3.5dBm -2dBm/3dBm 0dBm/5dBm
RX Sensitivity Max -17dBm -20dBm -22dBm -23dBm
Wavelength 850nm 1310nm 1310nm 1550nm
Assumed Fiber Loss .45dB/km .35dB/km .25dB/km
Laser Type VCSEL FP DFB DFB
Connectors
10/100BaseTX: Sixteen (16) RJ-45 Copper Ports
Optional SFP Ports:
1000BaseT:
Up to Two (2) RJ-45 Gigabit
Copper Ports (optional)
1000BaseSX: Up to Two (2) LC Duplex Gigabit
Fiber Ports (optional)
Recommended Wiring Clearance
Front:
4" (10.16 cm)
Side: 1" (2.54 cm)
Regulatory Approvals: 7018TX
FCC Title 47, Part 15, Subpart B - Class A; ICES-003 - Class A
UL Listed (US and Canada) 1604; ANSI/ISA-12.12.01-2007
Class I, Div 2, Groups A, B, C, D, and T4A
CE: EN61000-6-2:2001: EN61000-4-2, 3, 4, 5, 6
EN55011:1998+A1:1999+A2:2002-Class A
EN50155 for Railway Applications
GOST-R Certifi ed, RoHS Compliant
Designed to comply with:
IEEE 1613 for Electric Utility Substations
NEMA TS1/ TS2 for Traffi c control
Contact Information
N-TRON Corp. N-TRON Europe GmbH
820 S. University Blvd., Suite 4E Alte Steinhauserstr 19
Mobile, AL 36609 USA
6330 Cham / Zg Switzerland
TEL: (251) 342-2164 TEL: +41 41 7406636
FAX: (251) 342-6353 FAX: +41 41 7406637
Website: www.n-tron.com
Email: [email protected]
