Troubleshooting
Fast Easy Answers
The primary check for correct operation is the
device LEDs.
For advanced information, see the Configuration Manager
menu, at the top of Vlinx Modbus Gateway screen.
Select Diagnostic for a check of communications
status with attached MESP211 device, and then
select the device for which the communications
check is desired. A report of reply times and ping statistics is
generated and can be saved.
Select Monitor to review activity logs of attached MESP211
devices, then select the device for which logged information
is needed.
Logged information includes Time, Source &
Destination, Type of Event, Subscriber ID, Data
Collected, and Information the Vlinx Modbus
Gateway Manager program has gathered
since current login of the affected device.
Fast and easy on the web:
www.bb-elec.com
Q
uick
S
tart
G
uide
Ultra Compact MODBUS
Ethernet to Serial Gateways
MESP211
© 2012 B&B Electronics Manufacturing Company
1-888-948-2248 | Europe: +353 91 792444
www.bb-elec.com
Recommended Accessories
and Power Supplies
You can use your
smart phone to
access complete
documentation
on our website. Simply
scan the code to the
right.
DRAD35
MESP211
CD with software and manuals
Power supply
First Things First...
Before you begin, be sure you have
the following:
707 Dayton Road | PO Box 1040 | Ottawa, IL 61350
Phone: 815-433-5100 | Fax: 815-433-5109
www.bb-elec.com | E-mail: [email protected]
Ethernet Cables
Mode Switch
Result
Hold in for 0 - 2 seconds
Initiates a Hardware Reset
Hold in for 2 - 10 seconds
Enters Console Mode
Hold in for over 10 seconds
Reset to factory defaults
The Vlinx Modbus Gateway Manager defaults to options
like “Network” and “I don’t know the IP of the device.” If
the defaults meet your needs you don’t
need to set or change them.
If you have completed the configuration, click Save to
save the configuration to the serial server. Allow 15
seconds for the Gateway to reboot.
Click “Connect.” You should see a list of all devices on
the network, including your new device. If you do not
see your new device, please refer to the Troubleshooting
tips. You may now log out.
Continuing Section 6
Document number – pn710-08860-04_R1_MESP211_2713qsg
