Getting Started
Manual Documentation Number: PES1A/PESV1A-0712m 11
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
C C h h a a p p t t e e r r 3 3 : : G G e e t t t t i i n n g g S S t t a a r r t t e e d d
1. Check the contents of your PES1A/PESV1A package. It should
contain…
 The PES1A or PESV1A module
 A printed version of this user manual
 A printed version of the PES1A/PESV1A Quick Start Guide
 CD-ROM disc with discovery software, RealPort software, this manual, Quick
Start guide
2. Set up the Hardware
 Connect your PC to the network
 Connect the PES1A/PESV1A serial port to your serial device (Use a serial
cable if it is DCE, null modem cable if it is DTE.)
 Connect the PES1A/PESV1A Ethernet connector to a PoE-enabled network
switch or hub (CAT-5 cable)
3. Power it Up
 Power is applied when the Ethernet (PoE) cable is connected
 When a connection is established with the network the yellow LED will
illuminate
 The PES1A/PESV1A will automatically try to obtain an IP address, or
generate one itself
4. Get the IP Address
 Use the discovery software on your CD (finder.exe) to get the IP address for
your PES1A/PESV1A
5. Login
 In a web browser on your PC, type in the IP address and access the Web
Configuration and Management Interface

Login using the username „root‟ and password „dbps‟
