Note: The Vlinx Modbus Gateway Manager
software contains default parameter values
that are common to most Modbus networks.
1. Change the Description of the serial port if
needed.
2. Set the Mode to RS-232, RS-422 (4 wire),
RS-485 (2 wire) or RS-485 (4 wire).
3. Set the Baud Rate to control the speed of the port.
Valid rates range between 75 and 230.4k bits per
second.
4. Stop Bits controls the number of bits for end of
character.
5. Parity controls the error checking mode, with
options of No Parity, Odd, Even, Mark and Space.
Q
uick
S
tart
G
uide
Isolated Industrial MODBUS
Ethernet to Serial Gateways
MESR321
Document number – pn9759_MESR321-xx_r0_4212_qsg
Recommended Accessories
and Power Supplies 5 Set Up Serial Port
There are additional Modbus configuration pages that
may be accessed by selecting “Next” at the bottom of
each page, or by selecting the desired page from the
vertical list in the left-hand column.
The Vlinx Modbus Gateway Manager defaults to
options like “Network” and “I don’t know the IP of the
device.” If the defaults meet your needs you don’t
need to set or change them.
If you have completed the configuration, click Save to
save the configuration to the serial server. Allow 15
seconds for the Gateway to reboot.
Click “Connect.” You should see a list of all
devices on the network, including your new
device. If you do not see your new device,
please refer to the Troubleshooting tips.
You may now log out.
5 Finish and Log Out
