Troubleshooting
Fast East Answers
The primary check for correct operation is the
device LEDs.
For advanced information, see the Configuration
Manager menu, at the top of Vlinx Modbus
Gateway screen.
Select Diagnostic for a check of communications
status with attached MESR321 device, and then
select the device for which the communications
check is desired. A report of reply times and
ping statistics is generated and can be saved.
Select Monitor to review activity logs of attached
MESR321 devices, then select the device for
which logged information is needed.
Logged information includes Time, Source &
Destination, Type of Event, Subscriber ID, Data
Collected, and Information the Vlinx Modbus
Gateway Manager program has gathered
since current login of the affected device.
