DS-iMcV-Modules-1204
Copyright © 2012 IMC Networks. All rights reserved.
The information in this document is subject to
change without notice. IMC Networks assumes
no responsibility for any errors that may appear in
this document. Specific product names may be
trademarks or registered trademarks and are the
property of their respective companies. IMC Networks
Fiber Consulting Services
For information call:
TEL: 949-465-3000
1-800-624-1070 (US/CAN)
+32-16-550880 (Europe)
[email protected]
IMC Networks
Headquarters
19772 Pauling
Foothill Ranch, CA 92610
TEL: 949-465-3000
FAX: 949-465-3020
[email protected]
IMC Networks
Europe
Herseltsesteenweg 268
B-3200 Aarschot, Belgium
TEL: +32-16-550880
FAX: +32-16-550888
[email protected]
IMC Networks
Eastern US/Latin America
28050 U.S. Hwy. 19 North, Suite 306
Clearwater, FL 33761
TEL: 727-797-0300
FAX: 727-797-0331
[email protected]
Fiber Optics Specifications
For each product listed below in the Ordering Information section, the DISTANCE represents an approximate fiber distance based on industry-standard
fiber attenuation specifications. Actual distances will vary for each installation. For complete power budgets and information on calculating specific
distances, visit www.imcnetworks.com/go/fcs or contact IMC Networks Fiber Consulting Services at 949-465-3000.
* These products have single-strand fiber technology.
For more information go to: www.imcnetworks.com/products/SSFX.cfm
Ordering Information
Technical Specifications
PART NUMBER DESCRIPTION DISTANCE
iMcV-PIM 10 Mbps Modules
850-14940 TP/FO-MM850-ST 2 km
850-14941 TP/FO-MM850-SC 2 km
850-14942 TP/FO-MM1300-ST 2 km
850-14943 TP/FO-MM1300-SC 2 km
850-14944 TP/FO-SM1310/PLUS-ST 40 km
850-14945 TP/FO-SM1310/PLUS-SC 40 km
850-14946 TP/FO-SM1310/LONG-ST 40 km
850-14947 TP/FO-SM1310/LONG-SC 40 km
850-14949 TP/FO-SM1550/LONG-SC 80 km
PART NUMBER DESCRIPTION DISTANCE
IE-iMcV-Gigabit 1000 Mbps Modules
850-18510
850-18912 ^ IE-iMcV-Gigabit, TX/SFP § Varies
iMcV-Gigabit 1000 Mbps Modules ¥
850-15511 850-11913 ^ TX/SX-MM850-SC 220/550 m
850-15512 850-11914 ^ TX/LX-SM1310-SC 10 km
850-15513 850-11915 ^ TX/LX-SM1310/PLUS-SC 40 km
850-15514 850-11917 ^ TX/LX-SM1550/LONG-SC 80 km
850-15515 850-11918 ^ TX/LX-SM1550/XLONG-SC 100 km
iMcV-Gigabit 1000 Mbps Module Single-Strand Fiber *
850-15521 850-11834 ^ TX/SSLX-SM1310-SC (1550 rcv) 10 km
850-15522 850-11835 ^ TX/SSLX-SM1550-SC (1310 rcv) 10 km
850-15523 850-11836 ^ TX/SSLX-SM1310-SC (1490 rcv) 10 km
850-15524 850-11837 ^ TX/SSLX-SM1490-SC (1310 rcv) 10 km
850-15525 850-11844 ^ TX/SSLX-SM1310/PLUS-SC (1550 rcv) 40 km
850-15526 850-11845 ^ TX/SSLX-SM1550/PLUS-SC (1310 rcv) 40 km
850-15527 850-11846 ^ TX/SSLX-SM1310/PLUS-SC (1490 rcv) 30 km
850-15528 850-11847 ^ TX/SSLX-SM1490/PLUS-SC (1310 rcv) 30 km
850-15529 850-11848 ^ TX/SSLX-SM1310/LONG-SC (1550 rcv) 70 km
850-15530 850-11849 ^ TX/SSLX-SM1550/LONG-SC (1310 rcv) 70 km
PART NUMBER DESCRIPTION DISTANCE
iMcV-LIM 100 Mbps Modules ¥
850-15611 TX/FX-MM850-ST 2 km
850-15612 TX/FX-MM850-SC 2 km
850-15613 TX/FX-MM1300-ST 5 km
850-15614 TX/FX-MM1300-SC 5 km
850-15617 TX/FX-SM1310/PLUS-ST 40 km
850-15618 TX/FX-SM1310/PLUS-SC 40 km
850-15619 TX/FX-SM1310/LONG-ST 80 km
850-15620 TX/FX-SM1310/LONG-SC 80 km
850-15622 TX/FX-SM1550/LONG-SC 80 km
850-15623 TX/FX-SM1550/XLONG-SC 100 km
iMcV-LIM 100 Mbps Modules Single-Strand Fiber Modules *
850-15631 TX/SSFX-MM1310-SC (1550 rcv) 2 km
850-15632 TX/SSFX-MM1550-SC (1310 rcv) 2 km
850-15633 TX/SSFX-SM1310-SC (1550 rcv) 20 km
850-15634 TX/SSFX-SM1550-SC (1310 rcv) 20 km
850-15635 TX/SSFX-SM1310/PLUS-SC (1550 rcv) 40 km
850-15636 TX/SSFX-SM1550/PLUS-SC (1310 rcv) 40 km
850-15637 TX/SSFX-SM1310/LONG-SC (1550 rcv) 60 km
850-15638 TX/SSFX-SM1550/LONG-SC (1310 rcv) 60 km
Shipping Weight:
0.30 lbs (.11 kg)
Regulatory Approvals:
• FCC Class A
• FCC Class B (iMcV-LIM [100])
• CE
Operating Temperature:
+32° to +122° F (0° to +50° C);
-40° to +185° F (-40° to +85° C) IE-iMcV-Gigabit;
5% to 95% (non-condensing), 0 – 10,000 ft. altitude
Storage Temperature:
-13° to +158° F (-25° to +70° C);
5% to 95% (non-condensing)
IE-iMcV-Gigabit TX/SFP
• 1000Base-T twisted pair
• IE-SFP 1250 Mbps/1.25 Gbps
• AutoCross for MDI/MDIX
• Features FiberAlert, LinkLoss
& Link Fault Pass-Through
• Supports Config Control
All Modules
• Connectors: RJ-45 and ST, SC or SFP
• 50/125µm or 62.5/125µm multi-mode fiber
• 9/125µm single-mode fiber
• Install in any iMediaChassis or MediaChassis
• Support GUI-Based iView²
• Support Half- and Full-Duplex operation
• Include diagnostic LEDs
• Include hot-swappable architecture
iMcV-PIM
• 10Base-T twisted pair
• 10Base-FL fiber
• MDI/MDIX switch
• Features LinkLoss and
FiberAlert
iMcV-LIM (100)
• 100Base-TX twisted pair
• 100Base-FX or SX fiber
• AutoCross for MDI/MDIX
• Features LinkLoss, FiberAlert
& Auto Negotiation
• Features Link Fault
Pass-Through (LFPT)
• Supports Config Control
iMcV-LIM (10/100)
• 10Base-T twisted pair
• 10Base-FL fiber
• 100Base-TX twisted pair
• 100Base-FX or SX fiber
• MDI/MDIX switch
• Features Link Fault Detection
and Transparency
• Features Auto Negotiation
iMcV-Gigabit
• 1000Base-T twisted pair
• 1000Base-LX or SX fiber
• AutoCross for MDI/MDIX
• Features FiberAlert, LinkLoss
& Link Fault Pass-Through
• Supports Config Control
PART NUMBER DESCRIPTION DISTANCE
iMcV-LIM 10/100 Mbps Modules
850-14260 10/100-MM850-ST 2 km
850-14261 10/100-MM850-SC 2 km
850-14262 10/100-MM1300-ST 5 km
850-14263 10/100-MM1300-SC 5 km
850-14267 10/100-SM1310/PLUS-ST 40 km
850-14268 10/100-SM1310/PLUS-SC 40 km
850-14269 10/100-SM1310/LONG-ST 80 km
850-14270 10/100-SM1310/LONG-SC 80 km
850-14274 10/100-SM1550/LONG-SC 80 km
iMcV-LIM 10/100 Mbps Modules Single-Strand Fiber Modules *
850-14240 10/100-SSFX-MM1310-SC (1550 rcv) 2 km
850-14243 10/100-SSFX-MM1550-SC (1310 rcv) 2 km
850-14244 10/100-SSFX-SM1310-SC (1550 rcv) 20 km
850-14245 10/100-SSFX-SM1550-SC (1310 rcv) 20 km
850-14246 10/100-SSFX-SM1310/PLUS-SC (1550 rcv) 40 km
850-14247 10/100-SSFX-SM1550/PLUS-SC (1310 rcv) 40 km
850-14248 10/100-SSFX-SM1310/LONG-SC (1550 rcv) 60 km
850-14249 10/100-SSFX-SM1550/LONG-SC (1310 rcv) 60 km
§ SFP modules are sold separately. For more information on compatible IMC Networks SFPs,
go to: www.imcnetworks.com/Products/product.cfm?family=32
¥ CWDM wavelengths are also available. Contact IMC Networks for a complete list of part numbers.
^ Designates modules that DO NOT support Configuration Control or Link Fault Pass-Through.
