Scenario 1 – Basic Bridge
For added security, the 702M12-W supports WEP, WPA™, and WPA2™. WPA and WPA2, TKIP (Temporal Key Integrity
Protocol) and CCMP (Counter Mode with Cipher Block Chaining Message Authentication Code Protocol) are available.
Access Point:
The "Access Point" mode
a l l o w s t h e
702M12-W
to serve as a wireless
switch for the wireless
stations attached to it.
Station:
In "station" confi guration
the
702M12-W is used to
connect a single device
(MAC Address) to a
wireless access point.
In Station WDS mode the 702M12-W can be connected to a remote wired Ethernet switch with multiple devices connected
to the switch.
Scenario 2 – Control Network
