International Office: 707 Dayton Road PO Box 1040 Ottawa, IL 61350 USA 815-433-5100 Fax 433-5104
European Office: Westlink Commercial Park Oranmore Co. Galway Ireland +353 91 792444 Fax +353 91 792445
modular protocol-Independent,
10 gbps xFp Fiber mode converter
iMcV-10G Converter XFP
(dimensions in inches )
mEchanIcal dIagram
SpecificationS
Technical
2 x XFP ports
Supports copper and fiber XFP transceivers
Protocol-independent operation
Converts between dissimilar fiber modes and wavelengths
Includes diagnostic LEDs
Hot-swappable architecture
Modular Form Factor
Compatible with IMC Networks’ XFPs and all standard XFP transceivers
STandard compliance
SFF-8472 DDMI standard (Revision 1.0)
Mechanical
Dimensions
Dual-wide iMcV-module
Shipping Weight
0.25 lbs (0.11 kg)
environMental
Operating Temperature:
-4° to +158° F (-20° to +70° C)
Storage Temperature:
-40° to +185° F (-40° to +85° C)
Operating Humidity
5% to 95% (non-condensing),
0 – 10,000 ft. altitude
Power consuMPtion
637mA @ +70° C (Typical @ 5V)
regulatory aPProvals
FCC Class A
UL/cUL, CE
3.05
1.56
.31
4.19
1.02
2.74
.44
.15
3.33
.56
1.14
2.74
