Installing an iMcV-LIM 10/100
The iMcV Modules install in IMC Networks’ SNMP manageable iMediaChassis series
or in any MediaChassis.
NOTE
All modules are hot-swappable.
To install an iMcV Modules:
1. Remove the blank bracket covering the slot where the module is to be installed
by removing the screws on the outside edges of the bracket.
2. Slide the iMcV Modules into the chassis, via the cardguides, until the module is
seated securely in the connector.
3. Secure the module to the chassis by tightening the captive screw.
4. Save any “blanks” removed during installation for future use if the configuration
requirements change.
Managed Modules
To manage one or more iMcV-LIM 10/100, an SNMP agent must be present in the
chassis. To configure Managed Modules, install the module first, and then configure
using the management software. If using management software, software will
override hardware DIP Switch settings.
Unmanaged Modules
Before installing, configure the iMcV-LIM 10/100modules for desired features. Refer
to table which indicates the available features and settings for the iMcV-LIM 10/100
modules.
Dip
Switch
Feature Function Default
S1 LFD Link fault detection available in forced mode only (S3
is ON) OFF
S2 PNP
(AN)
Auto Negotiation mode (plug-n-play) available when
forced mode is disabled (S3 is OFF) ON
S3 Force Force mode forces the module to operate at 10 or 100
Mbps as determined by S4 OFF
S4 10/100 When ON, operates at 10 Mbps.
When OFF, operates at 100 Mbps.
Available when forced mode is enabled (S3 is ON)
OFF
Remaining DIP Switches are factory configured—DO NOT CHANGE
