Ip67 outdoor rated
Industrial wireless I/o
Zlinx Xtreme Wireless I/O
spECIFICatIons
rF ProPertieS
Physical Standard 802.15.4
FrequenCy
ZXT9-IO-xxxx 900 MHz ISM (902-928 MHz)
ZXT24-IO-xxxx 2.4 GHz ISM (2.4 to 2.5 GHz)
tranSMit Power
ZXT9-IO-xxxx
1 mW, 10 mW, 100 mW, 500 mW
1 W – Software Selectable
ZXT24-IO-xxxx
10 mW, 16 mW, 25 mW, 30 mW
63 mW – Software Selectable
reCeiVer SenSitiVity
ZXT9-IO-xxxx -100 dBm
ZXT24-IO-xxxx -105 dBm
oVer the air data rate
ZXT9-IO-xxxx
9.6 or 115.2 kbps
Software Selectable
ZXT24-IO-xxxx 250 kbps
outdoor range
ZXT9-IO-xxxx
Supplied Antenna 14 mi (23 km)
High Gain Antenna 40 mi (64 km)
ZXT24-IO-xxxx
Supplied Antenna 1.5 mi (2.4 km)
High Gain Antenna 10 mi (16 km)
Range estimates based on optimal RF conditions and an unobstructed line of sight.
tranSMiSSion Method
ZXT9-IO-xxxx FHSS
ZXT24-IO-xxxx DSSS
Modulation FSK
Channel CaPaCity
ZXT9-IO-xxxx 10 hop sequences share 50 frequencies
ZXT24-IO-xxxx 12 direct sequence channels
Network Topologies
I/O to I/O: One-to-one (Peer-to-Peer mode)
Radio Modem to I/O: One-to-many (Modbus I/O
mode)
enCryPtion
ZXT9-IO-xxxx 256 bit AES
ZXT24-IO-xxxx 128 bit AES
SuPPlied antenna
ZXT9-IO-xxxx
Impedance – 50 Ω
Connector – RPSMA Female
VSWR – 2.0 Max (in-band)
Gain – 3 dBi
Polarization – Vertical
Length – 7.8 in (198 mm)
ZXT24-IO-xxxx
Impedance - 50Ω
Connector – RPSMA Female
VSWR – 2.0 Max (in-band)
Gain – 2.1 dBi
Polarization – Vertical
Length – 4.38 in (113 mm)
Antenna Connection RPSMA Male
digital inPutS
Voltage Range
Configuration
0 to 48 VDC
PNP (default) / NPN (selectable)
Low Voltage (0) 1 VDC Maximum
High Voltage (1) Greater than 1 VDC
Pull Up/Down Current 38 µA
Frequency Input
2 DIs per module software selectable as counters with
0 to 20 KHz range
digital outPutS (relay)
Number of Relays 2
Type C (Normally Open and Normally Closed)
Output Connection 3 Terminals Per Relay (Common, NO, NC)
Comm. Connection 3.5 mm Terminal Block
Ratings 250 VAC @ 4 A, 30 VDC @ 4 A
analog inPutS / outPutS
Ranges
0 to 5 VDC, 0 to 10 VDC, 0 to 20 mA
4 to 20 mA
Resolution 16 bit (Inputs), 12 Bit (Outputs)
AI Load Resistance
100 MΩ - configured for Voltage
250 Ω - configured for Current
AO Output Current 1 mA maximum configured for Voltage
AO Source Load 450 Ω maximum configured for current
Input Protection Over voltage to 2x max input voltage
Power
Power Connector Terminal Block
Input Voltage 10 to 30 VDC
Power use
ZXT9-IO-xxxx 6.8 W (maximum)
ZXT24-IO-xxxx 4.5 W (maximum)
terMinal BloCkS
Wire Size 26 to 14 AWG
Torque 0.5 Nm (min) 0.6 Nm (max)
enVironMent
Dimensions 5.12x5.12x2.37 in /130.1x130.1x60.2 mm
Operating Temp -40 to 74°C (-40 to 165°F)
Storage Temp -40 to 85°C (-40 to 185°F)
Op Humidity 0 to 95% (Non-Condensing)
Enclosure Rating IP67
Use Indoor and Outdoor
CertiFiCationS
CE
EN55022: 2006 – Class A
EN61000-6-1: 2006 – Heavy Industrial
EN61000-4-2:2008 – ESD
EN61000-4-3:2006 – EFT
EN61000-4-6:2005 – Cond. Immunity
FCC
Class A
FCC ID – ZXT9-RM – OUR-9XTEND
FCC ID – ZXT24-RM – OUR-XBEEPRO
UL C1D2, File – E245458
ControlS and indiCatorS
Signal Strength 8 Green RSSI LED’s indicate signal strength
Power Green LED
Receive Data Green LED
Transmit Data Green LED
Programming Port USB
Reset Push Button
