secure, rugged wi-Fi modules
WLnn-XX-dp551 Series
SpecificationS
Technology
Technology IEEE 802.11a/b/g/n, Wi-Fi compliant
Frequency
2.4 ~ 2.4835 GHz (US/Canada/Europe)
5.150 ~ 5.350 GHz
5.725 ~ 5.825 GHz
Modulation Technology DSSS, CCK, OFDM
Modulation Type
DBPSK, DQPSK, CCK, BPSK, QPSK, 16QAM,
64QAM
Network Access Modes Infrastructure (Client), Ad Hoc
Channels
US/Canada: 11 Channels 802.11b/g
13 Channels 802.11a
Europe: 13 Channels 802.11b/g
19 Channels 802.11a
France: 4 Channels 802.11b/g
Japan: 14 Channels 802.11b
13 Channels 802.11g
23 Channels 802.11a
Wireless Data Rate
802.11b:11, 5.5, 2, 1 Mbps
802.11a/g: 54, 48, 36, 24, 18, 12, 9, 6 Mbps
802.11n: 65, 58.5, 42, 39, 26, 19.5, 13, 6.5 Mbps
MAC CSMA/CA with ACK, RTS, CTS
Network Protocols
TCP/IP, ARP, ICMP, DHCP, DHS, UDAP, TFTP, UDP,
PING
Receive Sensitivity 802.11 b/g
54Mb/s = -72 dBm
36Mb/s = -78 dBm
18Mb/s = -84 dBm
6Mb/s = -89 dBm
11Mb/s = -86 dBm
1Mb/s = -92 dBm
Receive Sensitivity 802.11 a
54Mb/s = -74 dBm
36Mb/s = -80 dBm
18Mb/s = -86 dBm
6Mb/s = -90 dBm
Transmit Power
802.11a/b/g
802.11b 15 dBm
802.11g 12.6 dBm
802.11a 17 dBm
Security Protocols
(Client mode)
Disabled, WEP 64 & 128bit, WPA (TKIP), WPA (AES),
WPA2 (AES), 802.1x (EAP) Supplicant 802.11I, WPA
& WPA2 Enterprise supplicants (EAP-TLS, EAP-
TTLS(MSCHAPv2), EAPTTLS(MDS5),
EAP-PEAPv0(MSCHAPv2, LEAP), EAP-FAST, LEAP)
Supports Certificates and Private Key Upload and
Storage (Multiple)
Antenna
Two (2) U.FL coaxial connectors, 50 Ohms
Max gain @ 5 GHz = 5.5 dBi
Max gain @ 2.4 GHz = 4.1 dBi
Supply 3.3VDC +/-5%, 650 mA (MAX)
Supply In-rush Current 1500mA (MAX) for 400us
DC Characteristics
Operating Current (Tx, 802.11g) = 370mA Typ.
Operating Current (Rx, 802.11g) = 200mA Typ.
Environmental
Operating Temperature: -40° to +85°C
Storage Temperature: -40° to +85°C
Relative humidity: 5% - 95% (non-condensing)
Vibration: 20G peak-to-peak, 20Hz-2KHz swept
Shock: 1500G peak-to-peak, 0.5mS duration
Interfaces
Dual UART (960KBAUD), RS232/ 422/ 485, SPI
(1bit/8MHz), 10/100 Ethernet, PortFlex
Digital I/O 8 GPIO
LED Indicators
4 indicator LED signals (RF ACT, POST, CONNECT, RF
LINK), Signal Strength
Connector
36 pin High Density SMT connector from Hirose (DF12-
36DS-0.5V), 4mm Height
Agency Approvals
North America: FCC Title 47 Part 15 Class B Sub C
Intentional Radiator, IOC RSS210
Europe: CE ETSI EN300 328
RoHS & WEEE compliant
