secure, rugged wi-Fi modules

WLnn-xx-dp551 Series

The AirborneM

2

M line of highly-integrated 802.11 wireless modules allow

OEMs to Wi-Fi enable devices used in an array of machine-to-machine
(M

2

M) applications. B&B delivers all of the necessary RF technology,

networking stacks and advanced security features in a compact, single-
board package, reducing integration costs for OEMs and providing for a
quick time to market.

Big Performance in Small and ruggedized Package
The AirborneM

2

M series delivers the industry’s most rugged, highly-

integrated, embedded Wi-Fi module solution. AirborneM

2

M modules meet

extended operating temperature and shock/vibration specifications of the
most demanding M

2

M applications.

Utilizing a 32bit ARM9 processor and the high-performance Atheros
AR6203 802.11 radio, the new AirborneM

2

M modules deliver increased

transmit power and receive sensitivity, contributing to superior range
performance.

Speedlink

roaming

The new AirborneM

2

M SpeedLink roaming feature provides enhanced

connection reliability, enabling OEM devices to roam freely within a
wireless network without loss of data or connection.

Flexible & easy to integrate
AirborneM

2

M incorporates support for both serial and Ethernet to Wi-Fi

802.11 2.4 or 5 GHz communications. Utilizing AirborneM

2

M PortFlex

capability, OEMs may configure via software any combination of UART,
SPI, Ethernet, GPIO and 802.11 interfaces. Each individual port can be
independently configured.

• Quick time to market and reduced integration costs
• 802.11a/b/g/n Wi-Fi (2.4 GHz, 5 GHz)
• Airborne PowerSave firmware reduces power consumption and

extends battery life in mobile devices

• Extended Operating Temperature Range (-40°C to +85°C) and

environmental specifications

• AirborneM

2

M SpeedLink roaming provides enhanced connection

reliability
• Advanced Enterprise Class wireless security
• AirborneM

2

M PortFlex capability enables any combination of comm

ports (UART, SPI, GPIO, Ethernet and 802.11 interfaces)

• FCC Part 15 Class B Sub C Modular Approval minimizes regulatory

requirements

• Backwards compatible with previous generations of AirborneM

2

M

embedded modules

produCt FEaturEs

ordErIng InFormatIon

Model nuMBer

deSCriPtion

WLNN-ER-DP551

802.11a/b/g/n, 10/100 Ethernet adapter, Advanced Enterprise

Security

WLNN-AN-DP551

802.11a/b/g/n, UART interface, Advanced Enterprise Security

WLNN-SE-DP551

802.11a/b/g/n, UART with RS-232/422/485 Driver Control,

Advanced Enterprise Security

WLNN-SP-DP551

802.11a/b/g/n, SPI interface, Advanced Enterprise Security

WLNN-EK-DP551

Design and Development Kit

The AirborneM

2

M modules are footprint and pin-compatible with their

predecessors. Our commitment to maintaining hardware and software
compatibility assures OEMs of a simple, future-proof migration path even as
wireless technology evolves.

enterprise Class Security
Security protocols are important to mission-critical wireless M

2

M

applications. AirborneM

2

M multi-layered security approach addresses the

requirements of Enterprise-class networks and corporate IT departments.
These advanced security features include wireless security (801.11i/WPA2
Enterprise); network security (EAP authentication and certificate support);
communication security (SSH functuionality and fully encrypted data
tunnels); and device security (multi-level encryption capability to protect
configuration data.)

aIrBornEm

2

m

tm

EmBEddEd dual

Band wIrElEss dEVICE sErVEr and

EthErnEt solutIon modulEs sErIal

& EthErnEt to 802.11a/B/g/n

(2.4 ghz, 5 ghz)

aCCEssorIEs

ACH2-DBAT-DP002 - 2 dBi portable (Rubber duck) 2.4/5 GHz antenna
ACH2-DBAT-DP003 - 3.8/5.5 dBi portable (Rubber duck) 2.4 GHz, 5 GHz antenna

World-wide.

Check with your local distributor for availability and options.

WLNN-xx-DP551 Series_3713ds
