100 Mb Fiber Transceiver Characteristics
® 2009 N-TRON, Corp. N-TRON and the N-TRON logo are trademarks of N-TRON, Corp. Product names mentioned herein are for identifi cation purposes only and
may be trademarks and/or registered trademarks of their respective company. Specifi cations subject to change without notice.
The responsibility for the use and application
of N-TRON products rests with the end user. N-TRON makes no warranties as to the fi tness or suitability of any N-TRON product for any specifi c application. N-TRON Corporation
shall not be liable for any damage resulting from the installation, use, or misuse of this product.
Printed in USA.
REV 090806
Contact Information
N-TRON Corp. N-TRON Europe GmbH
820 S. University Blvd., Suite 4E Alte Steinhauserstr 19
Mobile, AL 36609 USA
6330 Cham / Zg Switzerland
TEL: (251) 342-2164 TEL: +41 41 7406636
FAX: (251) 342-6353 FAX: +41 41 7406637
Website: www.n-tron.com
Email: [email protected]
716FX2 Industrial Ethernet Switch Ordering Information
716FX2-XX Fourteen 10/100BaseTX Ports, Two Multimode 100BaseFX Fiber Optic Ports
716FXE2-XX-YY Fourteen 10/100BaseTX Ports, Two Singlemode 100BaseFX Fiber Optic Ports
700-PM Panel Mount kit
URMK Universal Rack Mount Kit
NTPS-24-1.3 N-TRON Power Supply - (1.3 Amp @ 24VDC)
Where: XX = ST or SC
E = Singlemode, and Blank Otherwise
YY = 15, 40 or 80 for Singlemode, Blank for Multimode
* Multimode Fiber Optic Cable
** Singlemode Fiber Optic Cable
Connectors
10/100BaseTX: Fourteen (14) RJ-45 Copper Ports
100BaseFX: Two (2) SC or ST Fiber Duplex Ports
Recommended Wiring Clearance
Front : 4" (10.16 cm)
Side : 1" (2.54 cm)
Regulatory Approvals
FCC Title 47, Part 15, Subpart B - Class A; ICES-003 - Class A
UL Listed (US and Canada) 1604; ANSI/ISA-12.12.01-2007
Class I, Div 2, Groups A, B, C, D, and T4A
CE: EN61000-6-2:2001: EN61000-4-2, 3, 4, 5, 6
EN55011:1998+A1:1999+A2:2002-Class A
EN50155 for Railway applications
GOST-R Certifi ed, RoHS Compliant
Designed to comply with:
IEEE 1613 for Electric Utility Substations
NEMA TS1/ TS2 for Traffi c control
THE INDUSTRIAL NETWORK COMPANY
716FX2 Specifi cations
Switch Properties
Number of MAC Addresses: 8000
Aging Time: Programmable
Latency Typical: 2.6 μs
Switching Method: Store-and-Forward
Case Dimensions
Height: 2.3" (5.8 cm)
Width: 8.3" (21.0 cm)
Depth: 4,8" (12.1 cm)
Weight (max) 3.3 lbs (1.5 kg)
DIN-Rail Mount: 35mm
Electrical
Redundant Input Voltage: 10-30 VDC (Regulated)
Input Current (max): 620mA max. @ 24VDC
N-TRON Power Supply: NTPS-24-1.3 (1.3A@24V)
Environmental
Operating Temperature: -40 o C to 70 o C
Storage Temperature: -40 o C to 85 o C
Operating Humidity: 5% to 95%
(Non Condensing)
Operating Altitude: 0 to 10,000 ft.
Shock and Vibration (bulkhead mounted)
Shock: 200g @ 10ms
Vibration/Seismic: 50g, 5-200Hz, Triaxial
Reliability
MTBF: >2 Million Hours
Network Media
10BaseT: >Cat3 Cable
100BaseTX: >Cat5 Cable
100BaseFX Multimode: 50-62.5/125μm
100BaseFXE Singlemode: 7-10/125μm
Fiber Length 2km* 15km** 40km** 80km**
TX Power Min -19dBm/-14dBm -15dBm/-7dBm -5dBm/0dBm -5dBm/0dBm
RX Sensitivity Max -32dBm -34dBm -34dBm -34dBm
Wavelength 1310nm 1310nm 1310nm 1550nm
