The
N-TRON ® 716FX2
Industrial Ethernet switch combines
outstanding performance and ease of use. It is ideally suited for
connecting Ethernet enabled industrial and/or security equipment
and is a fully managed switch.
PRODUCT FEATURES
• Fourteen 10/100BaseTX RJ-45 Ports
• Two 100BaseFX Fiber ports, ST or SC style
• -40 o C to 70 o C Operating temperature
• ESD and Surge Protection Diodes on all Ports
• Auto Sensing 10/100BaseTX, Duplex, and MDIX
• Store-and-forward Technology
• Rugged DIN-Rail Enclosure
• Redundant Power Inputs (10-30VDC)
• Confi gurable Alarm Contact & Bi-Color Fault Status LED
Fully Managed Features:
• SNMP v1, v2, v3 and Web Browser Management
• Detailed Ring Map and Fault Location Charting
• N-Ring ™ Technology with ~30ms Healing
• N-View ™ OPC Monitoring
• N-Link ™ Redundant N-Ring Coupling
• Plug-and-play IGMP Support
• 802.1Q tag VLAN and Port VLAN
• 802.1p QoS and Port QoS
• EtherNet/IP™ CIP Messaging
• LLDP (Link Layer Discovery Protocol)
• Port Trunking
• Port Mirroring
• 802.1d, 802.1w, 802.1D RSTP
• DHCP Server, Option 82 relay, Option 61
Management Features
The 716FX2 offers several management functions that can be
easily confi gured using a web browser.
IGMP Snooping - Internet Group Management Protocol allows the
716FX2 switch to forward and fi lter multicast traffi c intelligently.
VLAN - Virtual Local Area Network allows you to segment the switch
in order to create two or more separate local area network domains.
QoS - Quality of Service provides prioritization of
network traffi c in order to provide better network service. QoS
improves the latency of prioritized Ethernet packets required for
ring management, real-time, and other interactive applications.
Port Trunking - Trunking (link aggregation) enables multiple
physical ports to be linked together and function as one uplink to
another N-TRON
trunking capable switch confi gured in the same
manner, thereby increasing the bandwidth between switches. This
confi guration can provide increased bandwidth and redundancy
to applications requiring high levels of fault tolerant operation.
Port Mirroring - Allows the traffi c on one port to be duplicated
and sent to a designated mirror port. Port mirroring is used to
monitor Ethernet traffi c on the designated source port using the
assigned mirror port.
DHCP - DHCP Server / Client automates the assignment of IP
addresses. DHCP Option 82 assures that if a device on a
specific port is replaced, the replacement receives the same
IP address as the original device.
THE INDUSTRIAL NETWORK COMPANY
Rapid Spanning Tree Protocol
RSTP allows the switch to be confi gured in a ring or mesh topology,
and provides support for redundant path communications with high
speed (rapid) healing.
Remote Monitoring Options
For ease of confi guration and monitoring, the 716FX2 offers web
browser management and N-View OLE for Process Control (OPC)
server software. The N-TRON
N-View software can be combined with
popular HMI software packages to add network traffi c monitoring,
trending, and alarming to any application using N-TRON
switches.
SNMP is also available for switch link and status monitoring. The alarm
contact and status LED can be confi gured to respond to power failure on
power input 1 or input 2,
N-Ring
Broken, Partial Break High, Partial
Break Low, or if multiple Ring managers are detected.
N-Ring Technology
N-TRON's 716FX2 Ring Manager using N-TRON's N-Ring
technology offers expanded ring size capacity, detailed fault
diagnostics, and a standard healing time of ~30ms. The 716FX2
ring
manager periodically checks the health of the ring via packets. If the
ring manager stops receiving these health check packets, it converts
the ring to a linear topology within ~30ms. When all switches in
the ring are N-TRON fully managed switches, a detailed ring map
and fault location chart will also be provided on the ring manager’s
web browser and OPC server to identfy the health status of the
ring. N-Link
™
allows the linking of two N-Rings. Up to 250 fully
managed N-TRON switches can participate in N-Ring topologies.
Industrial Packaging and Specifi cations
The 716FX2 is designed to operate in industrial environments. It
is housed in a rugged steel DIN-Rail enclosure. It has extended
industrial specifications and features to meet or exceed the
operating parameters of the connected equipment. These include
extended temperature ratings, extended shock and vibration specs,
redundant power inputs, and high MTBF (greater than 2M hours).
Ease of Use
The 10/100BaseTX ports are auto sensing and auto confi guring.
Each copper port is automatically negotiated for maximum speed
and performance by default, but can also be hard coded through the
user interface. A high speed processor allows wire speed capability
on all 100BaseTX ports simultaneously.
