File Name:DR-UPS40-SPEC 2007-04-02
D R - U P S 4 0
1.Back up connection for AC interruption
2.Combine redundancy module (DR-RDN20) to back up AC interruption or failure of PSU
Suggested Application
DC BAT
DR-UPS40
PSU 24V
24V/40A max. Load Battery
+ + - - +
+ +
-
- -
DC BAT
DR-UPS40 DR-RDN20
24V
PSU Load Battery
V in V out
A+ B+
+ + + - - -
+
+
+ -
- - -
-
40A DC UPS Module
