Instruction Manual & Software
The 232MSS2 comes with an instruction manual and software media. An IBM PC or compatible terminal stay resident
(TSR) program is supplied. The program allows the user to select the Smart Switch ports either through the command
line or by pressing a sequence of keys referred to as hot keys. The TSR requires 1K of memory. Also included is a
program written in Visual Basic, which allows you to switch ports in Windows 98, Windows NT 4.0 with service pack 3
installed, XP or Vista.
Power Supply
The 232MSS2 requires 12 VDC at 10 mA which is provided through a 2.5 mm power jack. The tip of the plug is positive
and the sleeve of the plug is ground. A power supply is available.
Power:
12 VDC to 16 VDC @ 10 mA
Dimensions: 12.2 x 7.1 x 2.3 cm (4.8 x 2.8 x 0.9 in)
DECLARATION OF CONFORMITY
Manufacturer’s Name: B&B Electronics Manufacturing Company
Manufacturer’s Address: P.O. Box 1040
707 Dayton Road
Ottawa, IL 61350 USA
Model Numbers: 232MSS2
Description: Four-Port Mini Smart Switch/Port Combiner
Type: Light industrial ITE equipment
Application of Council Directive: 89/336/EEC
Standards: EN 55022
EN 61000-6-1
EN 61000 (-4-2, -4-3, -4-4, -4-5, -4-6, -4-8, -4-11)
Michael J. Fahrion, Director of Engineering
