REV 090805
708M12-HV Specifi cations
Switch Properties
Number of MAC Addresses:
8000
Aging Time : Programmable
Latency Typical: 2.9 μs
Switching Method : Store-and-Forward
Case Dimensions
Height:
6.7" (16.9cm)
Width: 6.7" (16.9cm)
Depth (incl. DIN rail mount): 1.8" (4.6cm)
Weight (max): 3.4 lbs (1.6kg)
DIN-Rail Mount: 35mm (with optional clips)
Environmental
Operating Temperature:
-40 o C to 80 o C
Storage Temperature: -40 o C to 85 o C
Operating Humidity: 5% to 100%
(Non Condensing)
Operating Altitude: 0 to 10,000 ft.
N-TRON Power Supply: NTPS-24-1.3
Electrical
Redundant Input Voltage:
40-160 VDC
Input Current (max): 62mA max @124 VDC
Shock and Vibration (bulkhead mounted)
Shock:
200g @ 10ms
Vibration/Seismic: 50g, 5-200Hz, Triaxial
Reliability
MTBF:
>2 Million Hours
Network Media
10BaseT:
>Cat3 Cable
100BaseTX: >Cat5 Cable
Connectors
1 0/100BaseTX: Eight (8) M12 D-Coded
4 Pin Female Ports
RS-232 Com One (1) M12 A-Coded
5 Pin Female Port
NTCD-M12 One (1) M12 A-Coded
5 Pin Female Port
Recommended Wiring Clearance
Front
: ~4" (10.16cm)
Regulatory Approvals
FCC/CE CFR 47 Part 15, Subpart B, Class A
EN55022, ICES-003
EN 61000-4-3/4/5/6
EN50155 for Railway Applications
GS/CE: EN60950-1
708M12-HV Industrial Ethernet Switch
Ordering Information
708M12-HV IP67 rated Ethernet Switch with Eight
10/100BaseTX Ports with M12
D-Coded connectors, 40-DC
700-NTCD-M12 Confi guration device for saving and
restoring confi guration parameters
NTPS-48-2 DIN-Rail Power Supply 48V@2Amp
recommended for 708M12-HV
Cat5E STP Cables with M12 connectors
CAT5E-M12-M12-X Straight M12 to Str. M12, Shielded
CAT5E-M12-RJ45-X Straight M12 to RJ-45, Shielded
CAT5E-M12-X Straight M12 to bare end, Shielded
CAT5E-RM12-M12-X 90º M12 to Str. M12, Shielded
CAT5E-RM12-RM12-X 90º M12 to 90º M12, Shielded
CAT5E-RM12-RJ45-X 90º M12 to RJ-45, Shielded
CAT5E-RM12-X
90º M12 to bare end, Shielded
NTPS-48-2 DIN-Rail Power Supply 48V@2 Amp
PWR-M12-A-X Power Cable, M12 A-Coded Straight
Female to bare end, Shielded
PWR-RM12-A-X Power Cable, M12 A-Coded
90º Female to bare end, Shielded
SERIAL-DB9-M12 Serial cable, DB-9 to M12: 5 ft, shielded
SERIAL-DB9-RM12 Serial cable, DB-9 to 90 o M12,
5 ft, shielded
Where:
X = length of cable, fi ll in desired amount in feet.
Example: CAT5E-RM12-10 (for a 10ft cable)
