spECIFICatIons
rF ProPertieS
Physical Standard 802.15.4
FrequenCy
ZXT9-RM 900 MHz ISM (902-928 MHz)
ZXT24-RM 2.4 GHz ISM (2.4 to 2.5 GHz)
tranSMit Power
ZXT9-RM
1 mW, 10 mW, 100 mW, 500 mW
1 W – Software Selectable
ZXT24-RM
10 mW, 16 mW, 25 mW, 30 mW
63 mW – Software Selectable
Receiver Sensitivity -100 dBm
oVer the air data rate
ZXT9-RM 9.6 or 115.2 kbps
ZXT24-RM
Software Selectable
250 kbps
outdoor range
ZXT9-RM
Supplied Antenna 14 mi (23 km)
High Gain Antenna 40 mi (64 km)
ZXT24-RM
Supplied Antenna 1.5 mi (2.4 km)
High Gain Antenna 10 mi (16 km)
Range estimates based on optimal RF conditions and an unobstructed line of sight.
tranSMiSSion Method
ZXT9-RM FHSS
ZXT24-RM DSSS
Modulation FSK
Channel CaPaCity
ZXT9-RM 10 hop sequences share 50 Frequencies
ZXT24-RM 12 Direct Sequence Channels
Network Topologies
Peer-to-Peer, Point-to-Point,
Point-to-Multi Point
enCryPtion
ZXT9-RM 256 bit AES
ZXT24-RM 128 bit AES
SuPPlied antenna
ZXT9-RM
Impedance – 50 Ω
Connector – RPSMA Female
VSWR – 2.0 Max (in-band)
Gain – 3 dBi
Polarization – Vertical
Length – 7.8 in (198 mm)
ZXT24-RM
Impedance - 50Ω
Connector – RPSMA Female
VSWR – 2.0 Max (in-band)
Gain – 2.1 dBi
Polarization – Vertical
Length – 4.38 in (113 mm)
Modem Antenna Con. RPSMA Male
SoFtware
Support Win XP, 7
Features RSSI signal range test
Ip67 outdoor rated
Industrial radio modem
Zlinx Xtreme Wireless Radio Modems
Serial ProPertieS
data rates
ZXT9-RM
1.2 to 230.4 kbps
ZXT24-RM 1.2 to 115.2 kbps
Data Bits 8
Parity None, Even, Odd, Mark, Space
Stop Bits 1 or 2
Flow Control None or Software
RS-232
Connector: Terminal Block
Signals: TD, RD, RTS, CTS, GND
RS-422
Connector: Terminal Block
Signals: TDA(-) TDB(+) RDA(-) RDB(+) GND
RS-485 (2/4 Wire)
Connector: Terminal Block
Signals (4-Wire): TDA(-), TDB(+), RDA(-), RDB(+), GND
Signals (2-Wire): Data A(-), Data B(+), GND
SD Control Automatic Bit Wise
Termination 120Ω Ohm DIP Switch Selectable
Industrial Bus MODBUS RTU
Power
Power Connector Terminal Block
Input Voltage 10 to 30 VDC
Power Use
ZXT9-RM: 1.7 W (typical), 5.8 W (maximum)
ZXT24-RM: 1.2 W (typical), 3.5 W (maximum)
enVironMent
Dimensions 5.12x5.12x2.37 in /130.1x130.1x60.2 mm
Operating Temp -40° to 74°C (-40 to 165°F)
Storage Temp -40° to 85°C (-40 to 185°F)
Op Humidity 0 to 95% (Non-Condensing)
Enclosure Rating IP67
Use Indoor and Outdoor
CertiFiCationS
UL UL, cUL, Class 1 Div 2 Groups A, B, C, D File E245458
CE
EN55022: 2006 – Class A
EN61000-6-1: 2006 – Heavy Industrial
EN61000-4-2:2008 – ESD
EN61000-4-3:2006 – EFT
EN61000-4-6:2005 – Cond. Immunity
FCC
Class A
FCC ID – ZXT9-RM – OUR-9XTEND
FCC ID – ZXT24-RM – OUR-XBEEPRO
NEMA TS2
ControlS and indiCatorS
Signal Strength 8 Green RSSI LED’s indicate signal strength
Power Green LED
Receive Data Green LED
Transmit Data Green LED
Programming Port USB
Reset Push Button
