background image

www

.

bb

-

elec

.

com

|

Ip67 outdoor rated

Industrial radio modem

Zlinx Xtreme Wireless Radio Modems

Do you need to get a digital signal across a highway or river? Zlinx

®

Xtreme Radio Modems can do it faster, easier, and less expensively
than stringing cable. Easy plug-and-play set-up saves installation and
maintenance time. These compact and rugged IP67 units are ideal
for outdoor applications requiring Serial-to-Serial (RS-232/422/485)
connectivity or to connect Zlinx

®

Xtreme Wireless I/O’s to a Modbus RTU

Master over a wireless network. Point-to-Multi Point connections are
also possible.

Zlinx

®

Industrial Wireless products operate in license-free, Proprietary

RF 900 MHz and 2.4 GHz ISM bands. Select the 900 MHz version for
longer distances. For further flexibility, the output power is software
selectable.

The 900 MHz units offer 256 bit AES Encryption. The 2.4 GHz units have
128 bit AES Encryption.

• IP67 rated for outdoor applications
• RS-232/422/485, serial communications
• Modbus Compatible
• Ranges to 40 miles (64 km) Line of Sight & Antenna Dependent
• Heavy duty machine mount industrial grade case and components
• Signal strength indicator aids trouble shooting
• 900 MHz and 2.4 GHz versions
• Wide temperature range -40 to 74°C
• Wide range power input: 10VDC to 30VDC
• AES Encryption
• UL Class1/Division2
• NEMA TS2

ordErIng InFormatIon

Model nuMBer

deSCriPtion

ZXT9-RM

Zlinx Xtreme IP67 900MHz Radio Modem, Long Range,

RS- 232/422/485

ZXT24-RM

Zlinx Xtreme IP67 2.4GHz Radio Modem, Short Range,

RS-232/422/485

ZXT9-RM-KIT

Zlinx Xtreme IP67 900MHz Radio Modem Kit, (2) Radio

Modems, (2) 24VDC IP67 Power Supplies, (1) USB

Programming Cable

aCCEssorIEs

CLG-60-24

IP67 Power Supply, Panel Mount, 24V DC, 60W

ZXT9-ANT

900 MHz Spare Antenna

ZZ24D-ANT1

2.4 GHz Spare Antenna

ZXTMT

Zlinx Xtreme Conduit Kit

produCt FEaturEs

World-wide.

Check with your local distributor for availability and options.

* Check wireless regulations/standards in your geographic area.

Zlinx Xtreme Wireless Radio Modems_3713ds
