FRONT PANEL

From Top to Bottom:

Power LED

POE

POE Status LED

SPD

Speed LED (105TX-POE only)

LNK/ACT

Link/Activity LED

RJ45 Ports

Auto sensing 10/100BaseT Connection

LED MODE OF OPERATION

Note: Redundant power inputs will not balance the power load. Only load from one power supply is used
at a time.
