Troubleshooting
Fast East Answers
The primary check for correct operation is the
device LEDs.
For advanced information, see the Configuration
Manager menu, at the top of Vlinx Serial Server
Manager screen.
Select Diagnostic for a check of communications
status with attached VESR321 device, and then
select the device for which the communications
check is desired. A report of reply times and
ping statistics is generated and can be saved.
Note that you can send your configuration files
to B&B Tech Support for review.
Fast and easy on the web: www.bb-elec.com
Q
uick
S
tart
G
uide
Isolated Industrial
Ethernet to Serial Servers
VESR321
Document number – pn9758_VESR321-xx_r0_4212_qsg
© 2012 B&B Electronics Manufacturing Company
1-888-948-2248 | Europe: +353 91 792444
www.bb-elec.com
Recommended Accessories
and Power Supplies
Power Supply
http://www.bb-elec.PS12BVLB-INT-MED
DFMM-LCLC
Fiber Cable
http://search.bb-elec.com/?s=PPC_
GUIDE&q=DFMM-LCLC
You can use your
smart phone to
access complete
documentation
on our website. Simply
scan the code to the
right.
DFMM-LCLC
PS12BVLB-INT-MED
VESR321
CD with software and manuals
Mounting accessories kit
Additional items required but not included:
First Things First...
Before you begin, be sure you have
the following:
707 Dayton Road | PO Box 1040 | Ottawa, IL 61350
Phone: 815-433-5100 | Fax: 815-433-5109
www.bb-elec.com | E-mail: [email protected]
Ethernet Cables
http://search.bb-elec.com/?q=
ethernet+cable
Ethernet cable(s)
Null modem cable(s)
Power Supply for terminal block
or barrel connector
