MAX2387/MAX2388/MAX2389
W-CDMA LNA/Mixer ICs
4 _______________________________________________________________________________________
AC ELECTRICAL CHARACTERISTICS (continued)
(MAX238_ EV kit, V CC = 2.7V, SHDN = high, f RF_IN = f LNA_IN = 2140MHz, f LO = 2330MHz (f IF = 190MHz). Mixer, LNA, and LO input
ports are driven with 50 Ω sources. R
BIAS = 24k Ω ±1%, P
LO = -10dBm (MAX2387/MAX2388), P LO = -4dBm (MAX2389), P RF =
-30dBm. Typical values are at V CC = +2.7V, T A = +25°C, unless otherwise noted.)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
MAX2387 6
MAX2388 6
3 rd -Order Input Intercept Point
(Notes 1, 3)
IIP3 MXR
MAX2389 5
dBm
MAX2387 -13.9 -10
MAX2388 -16.3 -10.5
Input -1dB Compression Point
(Note 1)
IP
- 1dB,M XR
T
A
= -40°C to +85°C
MAX2389 -15.4 -10.5
dBm
MIXER PERFORMANCE (GAIN = LOW)
T A = +25 °C 7.5 9.0 10.5
Power Conversion Gain (Note 1) G MXR
T A = -40°C to +85°C 6.5 12.0
dB
MAX2387 6.9 8.4
MAX2388 6.1 7.4 Noise Figure (SSB) (Note 1) NF MXR T A = +25°C
MAX2389 6.6 8.8
dB
MAX2387 0.7
MAX2388 0.2
3 rd -Order Input Intercept Point
(Note 4)
IIP3 MXR T A = +25°C
MAX2389 1.3
dBm
MAX2387 -15.0 -10.7
MAX2388 -18.2 -11.3
Input -1dB Compression Point
(Note 1)
IP - 1dB,M XR T A = -40°C to +85°C
MAX2389 -17.8 -11.9
dBm
Note 1: Guaranteed by design and characterization.
Note 2: MIN guaranteed by production test, MAX guaranteed by design and characterization.
Note 3: Includes input matching circuit loss.
Note 4: fIN1 = 2140MHz, fIN2 = 2141MHz, PIN = -30dBm per tone.
Note 5: fIN1 = 2140MHz, fIN2 = 2141MHz, PIN = -25dBm per tone.
