MAX2387/MAX2388/MAX2389
W-CDMA LNA/Mixer ICs
_______________________________________________________________________________________ 3
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
Noise Figure (Notes 1, 3) NF LNA T A = +25°C 1.7 2.2 dB
3 rd -Order Input Intercept Point
(Note 4)
IIP3 LNA T A = -40°C to +85°C (Note 2) 4.2 dBm
Input -1dB Compression Point
(Note 1)
IP -1dB -19 -13 dBm
LNA PERFORMANCE: LOW-GAIN MODE (GAIN = LOW)
MAX2387 -18.5 -16.5 -14.5
T A = +25°C MAX2388/
MAX2389
-4.7 -2.8 -0.9
MAX2387 -10.5 -14
Gain G LNA
T A = -40°C to +85°C
(Note 2)
MAX2388/
MAX2389
5.4 -0.7
dB
MAX2387 19.2 21.3
Noise Figure (Notes 1, 3) NF LNA MAX2388/
MAX2389
6.5 8.4
dB
MAX2387 1
3 rd -Order Input Intercept Point
(Note 5)
IIP3 LNA MAX2388/
MAX2389
3.4
dBm
MAX2387 -9.9
Input -1dB Compression Point IP -1dB MAX2388/
MAX2389
-7.7
dBm
MIXER PERFORMANCE (GAIN = HIGH)
RF Frequency Range (Note 1) f RF 2110 2170 MHz
LO Frequency Range (Note 1) f LO 2250 2600 MHz
IF Frequency Range (Note 1) f IF 150 400 MHz
T A = +25°C 8.5 10 11.5
Power Conversion Gain G MXR
T
A
= -40°C to +85°C (Note 2) 7.5 12.5
dB
MAX2387 7.2 8.8
MAX2388 6.8 8.2 Noise Figure (SSB) (Note 1) NF MXR T A = +25°C
MAX2389 7.3 9.5
dB
AC ELECTRICAL CHARACTERISTICS (continued)
(MAX238_ EV kit, V CC = 2.7V, SHDN = high, f RF_IN = f LNA_IN = 2140MHz, f LO = 2330MHz (f IF = 190MHz). Mixer, LNA, and LO input
ports are driven with 50 Ω sources. R
BIAS = 24k Ω ±1%, P
LO = -10dBm (MAX2387/MAX2388), P LO = -4dBm (MAX2389), P RF =
-30dBm. Typical values are at V CC = +2.7V, T A = +25°C, unless otherwise noted.)
