MAX2387/MAX2388/MAX2389
W-CDMA LNA/Mixer ICs
S-PARAMETERS LNA (S11) LNA (S21) LNA (S12) LNA (S22)
FREQUENCY
(MHZ)
MAGNITUDE PHASE MAGNITUDE PHASE MAGNITUDE PHASE MAGNITUDE PHASE
600 0.83287 -41.655 5.2176 146.82 0.020023 79.051 0.92461 -15.535
700 0.81889 -43.792 5.0791 145.33 0.021153 78.88 0.9171 -16.23
800 0.80364 -46.486 4.9464 143.26 0.022406 78.412 0.91098 -17.187
900 0.78522 -49.489 4.7767 141.09 0.023962 79.181 0.90108 -18.177
1000 0.76638 -53.118 4.6109 138.2 0.025913 78.989 0.8914 -19.536
1100 0.74542 -56.424 4.4363 135.68 0.027189 79.621 0.87913 -20.759
1200 0.72614 -59.477 4.2861 133.2 0.028484 79.666 0.86957 -22.045
1300 0.70338 -62.232 4.1209 130.93 0.030015 80.686 0.85623 -23.156
1400 0.68291 -64.933 4.0146 128.4 0.030979 81.41 0.84504 -24.46
1500 0.66114 -67.298 3.8951 126.82 0.032236 82.856 0.83313 -25.525
1600 0.63958 -69.782 3.7818 124.53 0.033056 83.763 0.82095 -26.882
1700 0.61641 -72.041 3.6761 122.88 0.03398 85.56 0.80875 -28.147
1800 0.59303 -74.571 3.5823 120.51 0.035009 86.377 0.79497 -29.825
1900 0.56989 -76.974 3.5198 118.87 0.036332 88.572 0.78338 -31.503
2000 0.54509 -79.651 3.4376 116.77 0.036887 89.686 0.76891 -33.44
2100 0.52084 -82.452 3.3691 115.17 0.038318 91.409 0.75735 -35.559
2200 0.49554 -85.891 3.2858 112.47 0.039355 93.409 0.74365 -38.175
2300 0.47232 -89.473 3.2544 110.28 0.040817 94.973 0.73415 -41.034
2400 0.44892 -93.529 3.195 108.05 0.042049 97.086 0.72262 -44.165
2500 0.42766 -98.164 3.1347 105.62 0.043438 98.58 0.71335 -47.828
2600 0.40833 -103.42 3.06 102.94 0.044844 100.14 0.70474 -51.733
2700 0.39421 -109.16 2.9818 100.13 0.046899 101.7 0.70067 -56.04
2800 0.38321 -115.32 2.9149 96.964 0.048389 103.31 0.69795 -60.397
2900 0.37608 -121.52 2.821 94.462 0.049426 104.62 0.69514 -64.899
3000 0.37573 -128.03 2.7086 91.479 0.05079 106.39 0.69504 -69.425
3100 0.38123 -134.23 2.5802 88.528 0.051657 108.22 0.69915 -73.798
3200 0.39208 -139.73 2.4696 85.584 0.053915 110.43 0.70504 -77.625
3300 0.40626 -144.57 2.3296 83.264 0.055483 113.29 0.71095 -81.166
3400 0.42512 -148.8 2.2157 80.95 0.05783 115.29 0.71819 -84.4
3500 0.44708 -152.13 2.0519 79.588 0.060614 118.09 0.72516 -87.06
3600 0.47302 -154.7 1.9382 77.337 0.065129 119.23 0.73416 -89.168
3700 0.49849 -156.57 1.8048 76.594 0.069104 120.99 0.73997 -90.676
Table 1. LNA Input/Output S-Parameters (V CC = +2.7V, High-Gain Mode)
Package Information
For the latest package outline information, go to
www.maxim-ic.com/packages.
Maxim cannot assume responsibility for use of any circuitry other than circuitry entirely embodied in a Maxim product. No circuit patent licenses are
implied. Maxim reserves the right to change the circuitry and specifications without notice at any time.
