MAX1036–MAX1039
2.7V to 5.5V, Low-Power, 4-/12-Channel
2-Wire Serial 8-Bit ADCs
_______________________________________________________________________________________
5
ELECTRICAL CHARACTERISTICS (continued)
(V
DD
= 2.7V to 3.6V (MAX1037/MAX1039), V
DD
= 4.5V to 5.5V (MAX1036/MAX1038). External reference, V
REF
= 2.048V
(MAX1037/MAX1039), V
REF
= 4.096V (MAX1036/MAX1038). External clock, f
SCL
= 1.7MHz, T
A
= T
MIN
to T
MAX
, unless otherwise
noted. Typical values are at T
A
= +25°C.)
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Setup Time for a Repeated START
Condition (Sr)
t
SU
,
STA
160
ns
Data Hold Time
t
HD
,
DAT
(Note 12)
0
150
ns
Data Setup Time
t
SU
,
DAT
10
ns
Rise Time of SCL Signal
(Current Source Enabled)
t
RCL
(Note 13)
20
80
ns
Rise Time of SCL Signal After
Acknowledge Bit
t
RCL1
(Note 13)
20
160
ns
Fall Time of SCL Signal
t
FCL
(Note 13)
20
80
ns
Rise Time of SDA Signal
t
RDA
(Note 13)
20
160
ns
Fall Time of SDA Signal
t
FDA
(Note 13)
20
160
ns
Setup Time for STOP Condition
t
SU
,
STO
160
ns
Capacitive Load for Each Bus Line
C
B
400
pF
Pulse Width of Spike Suppressed
t
SP
0
10
ns
Note 1: The MAX1036/MAX1038 are tested at V
DD
= 5V and the MAX1037/MAX1039 are tested at V
DD
= 3V. All devices are config-
ured for unipolar, single-ended inputs.
Note 2: Relative accuracy is the deviation of the analog value at any code from its theoretical value after the full-scale range and
offsets have been calibrated.
Note 3: Offset nulled.
Note 4: Ground ON channel; sine wave applied to all OFF channels.
Note 5: Conversion time is defined as the number of clock cycles (8) multiplied by the clock period. Conversion time does not
include acquisition time. SCL is the conversion clock in the external clock mode.
Note 6: The absolute voltage range for the analog inputs (AIN0–AIN11) is from GND to V
DD
.
Note 7: When AIN_/REF is configured to be an internal reference (SEL[2:1] = 11), decouple AIN_/REF to GND with a 0.01µF capacitor.
Note 8: The switch connecting the reference buffer to AIN_/REF has a typical on-resistance of 675
Ω.
Note 9: ADC performance is limited by the converter’s noise floor, typically 1.4mV
P-P
.
Note 10: Electrical characteristics are guaranteed from V
DD(min)
to V
DD(max)
. For operation beyond this range, see the Typical
Operating Characteristics.
Note 11: Power-supply rejection ratio is measured as:
, for the MAX1037/MAX1039 where N is the number of bits (8) and V
REF
= 2.048V.
Power-supply rejection ratio is measured as:
, for the MAX1036/MAX1038 where N is the number of bits (8) and V
REF
= 2.048V.
Note 12: A master device must provide a data hold time for SDA (referred to V
IL
of SCL) in order to bridge the undefined region of
SCL’s falling edge (Figure 1).
Note 13: C
B
= total capacitance of one bus line in pF. t
R
and t
F
measured between 0.3V
DD
and 0.7V
DD
. Minimum specification is
tested at +25°C with C
B
= 400pF.
Note 14: f
SCLH
must meet the minimum clock low time plus the rise/fall times.
V
V
V
V
V
V
V
FS
FS
N
REF
5 5
4 5
2
5 5
4 5
.
.
.
.
(
)
−
(
)
[
]
×
−
V
V
V
V
V
V
V
FS
FS
N
REF
3 3
2 7
2
3 3
2 7
.
.
.
.
(
)
−
(
)
[
]
Ч
−
