MAX1365/MAX1367

Stand-Alone, 4.5-/3.5-Digit Panel Meters
with 4–20mA Output

2

_______________________________________________________________________________________

ABSOLUTE MAXIMUM RATINGS

ELECTRICAL CHARACTERISTICS

(AV

DD

= DV

DD

= DAC_VDD = +2.7V to +5.25V, GND = 0, V

LEDV

= +2.7V to +5.25V, LEDG = 0, V

REF+

- V

REF-

= 2.048V (external

reference), 4-20OUT = 7V, V

REG_AMP

= +5.0V, C

REF+

= 0.1µF, REF- = GND, C

NEGV

= 0.1µF. Internal clock mode, unless otherwise

noted. All specifications are at T

A

= T

MIN

to T

MAX

. Typical values are at T

A

= +25°C, unless otherwise noted.)

Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.

AV

DD,

DV

DD ....................................................................

-0.3V to +6.0V

AIN+, AIN-, REF+, REF-.........................V

NEGV

to (AV

DD

+ 0.3V)

REG_FORCE, CMP, DAC_VDD, DACVOUT,

CONV_IN, 4-20OUT .............................-0.3V to (AV

DD

+ 0.3V)

EN_BPM, EN_I, REFSELE, DACDATA_SEL, INTREF, RANGE,

DPSET1, DPSET2, HOLD, PEAK, DPON,
CS_DAC...............................................-0.3V to (DV

DD

+ 0.3V)

NEGV .......................................................-2.6V to (AV

DD

+ 0.3V)

LED_EN....................................................-0.3V to (DV

DD

+ 0.3V)

SET...........................................................-0.3V to (AV

DD

+ 0.3V)

REG_AMP, REG_VDD ...........................................-0.3V to +6.0V
LEDV......................................................................-0.3V to +6.0V
LEDG .....................................................................-0.3V to +0.3V
GND_DAC .............................................................-0.3V to +0.3V
GND_V/I.................................................................-0.3V to +0.3V

SEG_ to LEDG.........................................-0.3V to (V

LEDV

+ 0.3V)

DIG_ to LEDG..........................................-0.3V to (V

LEDV

+ 0.3V)

REF_DAC .................................................-0.3V to (AV

DD

+ 0.3V)

DIG_ Sink Current .............................................................300mA
DIG_ Source Current...........................................................50mA
SEG_ Sink Current . ............................................................50mA
SEG_ Source Current..........................................................50mA
Maximum Current Input into Any Other Pin . ......................50mA
Continuous Power Dissipation (T

A

= +70°C)

48-Pin TQFP (derate 22.7mW/°C above +70°C).....1818.2mW

Operating Temperature Range ...........................-40°C to +85°C
Storage Temperature Range .............................-60°C to +150°C
Junction Temperature ......................................................+150°C
Lead Temperature (soldering, 10s) .................................+300°C

PARAMETER

SYMBOL

CONDITIONS

MIN

TYP

MAX

UNITS

ADC ACCURACY

MAX1365

-19,999

+19,999

Noise-Free Resolution

MAX1367

-1999

+1999

Counts

2.000V range

±1

Integral Nonlinearity (Note 1)

INL

200mV range

±1

Counts

Range Change Ratio

(V

AIN+

- V

AIN-

= 0.100V) on 200mV range;

(V

AIN+

- V

AIN-

= 0.100V) on 2.0V range

10:1

Ratio

Rollover Error

V

AIN+

- V

AIN-

= full scale

±1

Counts

Output Noise

10

µV

P-P

Offset Error (Zero Input Reading)

V

AIN+

- V

AIN-

= 0 (Note 2)

-0

+0

Counts

Gain Error

(Note 3)

-0.5

+0.5

%FSR

Offset Drift (Zero Reading Drift)

V

AIN+

- V

AIN-

= 0 (Note 4)

0.1

µV/°C

Gain Drift

±1

ppm/°C

INPUT CONVERSION RATE

Update Rate

5

Hz

ANALOG INPUTS (AIN+, AIN-) (bypass to GND with 0.1µF or greater capacitors)

RANGE = GND

-2.0

+2.0

AIN Input Voltage Range (Note 5)

RANGE = DV

DD

-0.2

+0.2

V

AIN Absolute Input Voltage
Range to GND

-2.2

+2.2

V

Normal-Mode 50Hz and 60Hz
Rejection (Simultaneously)

50Hz and 60Hz ±2%

100

dB
