MAX907/MAX908/MAX909
Dual/Quad/Single, High-Speed, Ultra-Low-Power,
Single-Supply TTL Comparators
V
CLAMP
= -200mV TO -300mV
I
SRC
V-
1/2 MAX907
Figure 3. Schottky Clamp for Input Driven Below Ground
10pF
1M
Ω
+5V
6
7
+5V
0.1
µF
DATA
2
3
4
100k
Ω
SIEMENS BP-104
PHOTODIODE
100k
Ω
+5V
1000pF
1000pF
47k
Ω
2
3
0.1
µF
4
8
1
MAX907
MAX403
Figure 4. Battery-Operated Infrared Data Link Consumes Only
1mA
Pin Configurations (continued)
Ordering Information (continued)
1
2
3
4
8
7
6
5
QOUT
QOUT
GND
LE
V-
IN-
IN+
V+
MAX909
DIP/SO
TOP VIEW
PART
TEMP. RANGE
PIN-PACKAGE
MAX908CPD
0°C to +70°C
14 Plastic DIP
MAX908CSD
0°C to +70°C
14 SO
MAX908EPD
-40°C to +85°C
14 Plastic DIP
MAX908ESD
-40°C to +85°C
14 SO
MAX909CPA
0°C to +70°C
8 Plastic DIP
MAX909CSA
0°C to +70°C
8 SO
MAX909EPA
-40°C to +85°C
8 Plastic DIP
MAX909ESA
-40°C to +85°C
8 SO
Chip Information
MAX907 TRANSISTOR COUNT: 262
MAX908 TRANSISTOR COUNT: 536
MAX909 TRANSISTOR COUNT: 140
PROCESS: Bipolar
Maxim cannot assume responsibility for use of any circuitry other than circuitry entirely embodied in a Maxim product. No circuit patent licenses are
implied. Maxim reserves the right to change the circuitry and specifications without notice at any time.
10 _____________________Maxim Integrated Products, 120 San Gabriel Drive, Sunnyvale, CA 94086 408-737-7600
© 2001 Maxim Integrated Products Printed USA
