General Description
The MAX1820/MAX1821 low-dropout, pulse-width-mod-
ulated (PWM) DC-DC buck regulators are optimized to
provide power to the power amplifier (PA) in WCDMA
cell phones; however, they may be applied in many
other applications where high efficiency is a priority. The
supply voltage range is from 2.6V to 5.5V, and the guar-
anteed output current is 600mA; 1MHz PWM switching
allows for small external components, while skip mode
reduces quiescent current to 180µA with light loads.
The MAX1820 is dynamically controlled to provide vary-
ing output voltages from 0.4V to 3.4V. The circuit is
designed such that the output voltage settles in <30µs
for a full-scale change in voltage and current. The
MAX1821 is set with external resistors to provide any
fixed output voltage in the 1.25V to 5.5V range.
The MAX1820/MAX1821 include a low on-resistance
internal MOSFET switch and synchronous rectifier to
maximize efficiency and minimize external component
count; 100% duty-cycle operation allows for low dropout
of only 150mV at 600mA load, including the external
inductor resistance. The devices are offered in 10-pin
µMAX and tiny 3
✕
4 chip-scale (UCSP™) packages.
________________________Applications
WCDMA Cell Phone Power Amplifiers
PDA, Palmtop, and Notebook Computers
Microprocessor Core Supplies
Digital Cameras
PCMCIA and Network Cards
Hand-Held Instruments
Features
♦ Dynamically Adjustable Output from 0.4V to 3.4V
(MAX1820)
♦ Programmable Output from 1.25V to 5.5V
(MAX1821)
♦ SYNC to 13MHz External Clock (MAX1820X)
♦ SYNC to 19.8MHz External Clock (MAX1820Y)
♦ NO SYNC, Internal 1MHz Oscillator (MAX1820Z)
♦ Low Quiescent Current
180µA (typ) in Skip Mode
0.1µA (typ) in Shutdown Mode
♦ No External Schottky Diode Required
♦ 600mA Guaranteed Output Current
♦ 0% to 100% Duty-Cycle Operation
♦ 150mV Dropout at 600mA Load (Including R
DC
of External Inductor)
♦ µMAX or UCSP Packaging
MAX1820/MAX1821
WCDMA Cellular Phone 600mA
Buck Regulators
________________________________________________________________ Maxim Integrated Products
1
19-2011; Rev 2; 7/02
EVALUATION KIT
AVAILABLE
Ordering Information
PART
SYNC
FREQ (MHz)
OUTPUT VOLTAGE
TEMP RANGE
PIN-PACKAGE
UCSP MARK
MAX1820ZEBC*
No Sync
Dynamic
-40°C to +85°C
3
✕
4 UCSP
AAB
MAX1820YEBC*
19.8
Dynamic
-40°C to +85°C
3
✕
4 UCSP
AAL
MAX1820XEBC*
13
Dynamic
-40°C to +85°C
3
✕
4 UCSP
AAM
MAX1820ZEUB
No Sync
Dynamic
-40°C to +85°C
10 µMAX
—
MAX1820YEUB
19.8
Dynamic
-40°C to +85°C
10 µMAX
—
MAX1820XEUB
13
Dynamic
-40°C to +85°C
10 µMAX
—
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim’s website at www.maxim-ic.com.
Pin Configurations appear at end of data sheet.
Typical Operating Circuits continued at end of data sheet.
SYNC
GND
SHDN
BATT
PGND
COMP
V
OUT
CONTROL
DAC
REF
LX
OUT
13MHz
OR
19.8MHz
MAX1820
SKIP
4.7
µH
4.7
µF
INPUT
2.6V TO
5.5V
DYNAMIC
OUTPUT
0.4V TO 3.4V
Typical Operating Circuits
