ELECTRICAL CHARACTERISTICS
(V
DD
= +3V, OV
DD
= +2.5V; 0.1µF and 1.0µF capacitors from REFP, REFN, and COM to GND; REFOUT connected to REFIN through
a 10k
Ω resistor, V
IN
= 2V
p-p
(differential w.r.t. COM), C
L
= 10pF at digital outputs (Note 5), f
CLK
= 83.333MHz (50% duty cycle), T
A
=
T
MIN
to T
MAX
, unless otherwise noted. Typical values are at T
A
= +25°C.)
MAX1181
Dual 10-Bit, 80Msps, +3V, Low-Power ADC with
Internal Reference and Parallel Outputs
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
V
DD
, OV
DD
to GND ...............................................-0.3V to +3.6V
OGND to GND.......................................................-0.3V to +0.3V
INA+, INA-, INB+, INB- to GND ...............................-0.3V to V
DD
REFIN, REFOUT, REFP, REFN, CLK,
COM to GND ............................................-0.3V to (V
DD
+ 0.3V)
OE, PD, SLEEP, T/B, D9A–D0A,
D9B–D0B to OGND ................................-0.3V to (OV
DD
+ 0.3V)
Continuous Power Dissipation (T
A
= +70°C)
48-Pin TQFP (derate 12.5mW/°C above +70°C).........1000mW
Operating Temperature Range ...........................-40°C to +85°C
Junction Temperature ......................................................+150°C
Storage Temperature Range .............................-60°C to +150°C
Lead Temperature (soldering, 10s) .................................+300°C
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
DC ACCURACY
Resolution
10
Bits
Integral Nonlinearity
INL
f
IN
= 7.47MHz
±0.6
±2.2
LSB
Differential Nonlinearity
DNL
f
IN
= 7.47MHz, no missing codes guaranteed
±0.4
±1.0
LSB
Offset Error
<
±1
±1.7
% FS
Gain Error
0
±2
% FS
ANALOG INPUT
Differential Input Voltage Range
V
DIFF
Differential or single-ended inputs
±1.0
V
Common-Mode Input Voltage
Range
V
CM
V
DD
/2
± 0.5
V
Input Resistance
R
IN
Switched capacitor load
25
k
Ω
Input Capacitance
C
IN
5
pF
CONVERSION RATE
Maximum Clock Frequency
f
CLK
80
MHz
Data Latency
5
Clock
Cycles
DYNAMIC CHARACTERISTICS (f
CLK
= 83.333MHz, 4096-point FFT)
f
INA or B
= 7.47MHz, T
A
= +25
°C
56.5
59.5
f
INA or B
= 20MHz, T
A
= +25
°C
56
59
Signal-to-Noise Ratio
SNR
f
INA or B
= 39.9MHz (Note 1)
59
dB
f
INA or B
= 7.47MHz, T
A
= +25
°C
56
59
f
INA or B
= 20MHz, T
A
= +25
°C
55.3
58.5
Signal-to-Noise And Distortion
(up to 5
th
harmonic)
SINAD
f
INA or B
= 39.9MHz (Note 1)
58.5
dB
f
INA or B
= 7.47MHz, T
A
= +25
°C
65
75
f
INA or B
= 20MHz, T
A
= +25
°C
64
73
Spurious-Free Dynamic
Range
SFDR
fINA or B
= 39.9MHz, (Note 1)
71
dBc
f
INA or B
= 7.47MHz
-76
f
INA or B
= 20MHz
-76
Third-Harmonic Distortion
HD3
f
INA or B
= 39.9MHz (Note 1)
-75
dBc
