3)Standard packaged quantity and IC direction
The standard packaged quantity is 3,000 pcs/reel. Orders should be in multiples of the standard packaged
quantity. The ICs are TR oriented (as shown below).
Symbol
Dimension
A
180 Max.
B
60±2.0
D
20.2 Min.
E
1.5 Min.
W
9.0±0.3
t
Label side(1.0)
Back side(1.2)
TMax.
17.4
C
13.0±0.5
(mm)
First pin
D
A W
T MAX
t
C
B
E
Fig.39
(Leader side)
Fig.40
2)Dimension of reel
13/15
Voltage detectors
BD48XXG/FVE
BD49XXG/FVE
Rev.A
