Pin Descriptions and Equivalent Circuits

Pin No.

Symbol

Equivalent Circuit

Description

6

V

IN

Analog signal input. Conversion range is V

RB

to V

RT

.

3

V

RT

Analog Input that is the high (top) side of the reference

ladder of the ADC. Nominal range is 0.5V to V

A

. Voltage

on V

RT

and V

RB

inputs define the V

IN

conversion range.

Bypass well. See Section 2.0 for more information.

9

V

RM

Mid-point of the reference ladder. This pin should be

bypassed to a quiet point in the analog ground plane with

a 0.1 µF capacitor.

10

V

RB

Analog Input that is the low side (bottom) of the

reference ladder of the ADC. Nominal range is 0.0V to

(V

RT

– 0.5V). Voltage on V

RT

and V

RB

inputs define the

V

IN

conversion range. Bypass well. See Section 2.0 for

more information.

23

PD

Power Down input. When this pin is high, the converter is

in the Power Down mode and the data output pins hold

the last conversion result.

24

CLK

CMOS/TTL compatible digital clock Input. V

IN

is sampled

on the rising edge of CLK input.

13 thru 16

and

19 thru 22

D0–D7

Conversion data digital Output pins. D0 is the LSB, D7 is

the MSB. Valid data is output after the rising edge of the

CLK input.

7

V

IN

GND

Reference ground for the single-ended analog input, V

IN

.

1, 4, 12

V

A

Positive analog supply pin. Connect to a quiet voltage

source of +3V. V

A

should be bypassed with a 0.1 µF

ceramic chip capacitor for each pin, plus one

10 µF capacitor. See Section 3.0 for more information.

18

V

DR

Power supply for the output drivers. If connected to V

A

,

decouple well from V

A

.

17

DR GND

The ground return for the output driver supply.

2, 5, 8, 11

AGND

The ground return for the analog supply.

ADC08L060

www.national.com

3
